Nilan CTS602
Controller for Nilan ventilation units with heat pump, hot water and central heating.
The Nilan CTS602 is the controller in Nilan ventilation units with heat recovery that can also run a heat pump, a hot water tank and central heating. This Modbus RTU template reads all temperatures, humidity, CO2, fan steps, operating state and alarms, and lets you switch the unit, change mode, ventilation step and setpoints from ModbusCloud.
- Protocol
- Modbus RTU
- Connection
- RS485, 19200 baud
- Registers
- 314, read and write
- Brand
- Nilan
- Key readings
- Outdoor and supply temperatures · Room and exhaust temperature · Hot water temperatures · Humidity and CO2 · Fan steps and speeds · Operating mode and state · Active alarms · Days to filter change
- Available commands
- On and off · Operating mode · Ventilation step · Room temperature setpoint · Hot water setpoints · Alarm reset
- Compatible models
- CTS602 · CTS602 with HMI350T panel
- Last updated
Registers (314)
314 read, 151 write
| Name | Unit | Access | Address (Hidden until you enter your email) | Function (hidden) | Type (hidden) |
|---|---|---|---|---|---|
| Protocol Version | Read | ||||
| Software Version Major | Read | ||||
| Software Version Minor | Read | ||||
| Software Version Release | Read | ||||
| Application Id | Read | ||||
| Hardware Type | Read | ||||
| User Function Input | Read | ||||
| Air Filter Alarm Input | Read | ||||
| Door Contact Input | Read | ||||
| Smoke Alarm Input | Read | ||||
| Motor Thermo Fuse Input | Read | ||||
| Heating Surface Frost Overheat Input | Read | ||||
| Airflow Monitor Input | Read | ||||
| High Pressure Switch Input | Read | ||||
| Low Pressure Switch Input | Read | ||||
| Hot Water Boiling Input | Read | ||||
| Hot Water 3-Way Valve Position Input | Read | ||||
| Hotgas Defrost Type Input | Read | ||||
| Defrost Thermostat Input | Read | ||||
| User Function 2 Input | Read | ||||
| Air Damper Closed Input | Read | ||||
| Air Damper Opened Input | Read | ||||
| FC And Thermo Alarm Input | Read | ||||
| Brine Pressostat Input | Read | ||||
| T0 Controller Temperature | °C | Read | |||
| T1 Fresh Air Intake Temperature | °C | Read | |||
| T2 Inlet Temperature Before Heater | °C | Read | |||
| T3 Room Exhaust Temperature | °C | Read | |||
| T4 Outlet Temperature | °C | Read | |||
| T5 Condenser Temperature | °C | Read | |||
| T6 Evaporator Temperature | °C | Read | |||
| T7 Inlet Temperature After Heater | °C | Read | |||
| T8 Outdoor Temperature | °C | Read | |||
| T9 Heating Surface Temperature | °C | Read | |||
| T10 External Room Temperature | °C | Read | |||
| T11 Hot Water Top Temperature | °C | Read | |||
| T12 Hot Water Bottom Temperature | °C | Read | |||
| T13 Central Heating Return Temperature | °C | Read | |||
| T14 Central Heating Supply Temperature | °C | Read | |||
| T15 User Panel Room Temperature | °C | Read | |||
| T16 AUX Temperature | °C | Read | |||
| T17 Preheater Intake Temperature | °C | Read | |||
| T18 Pressure Pipe Temperature | °C | Read | |||
| Suction Pressure | bar | Read | |||
| Discharge Pressure | bar | Read | |||
| Humidity | %RH | Read | |||
| CO2 | ppm | Read | |||
| Alarm Status | Read | ||||
| Alarm 1 Code | Read | ||||
| Alarm 1 Date | Read | ||||
| Alarm 1 Time | Read | ||||
| Alarm 2 Code | Read | ||||
| Alarm 2 Date | Read | ||||
| Alarm 2 Time | Read | ||||
| Alarm 3 Code | Read | ||||
| Alarm 3 Date | Read | ||||
| Alarm 3 Time | Read | ||||
| Actual On Off State | Read | ||||
| Actual Operation Mode | Read | ||||
| Actual Control State | Read | ||||
| Time In State | s | Read | |||
| Ventilation Step Setpoint | Read | ||||
| Inlet Fan Step | Read | ||||
| Exhaust Fan Step | Read | ||||
| Days Since Filter Alarm | d | Read | |||
| Days To Filter Alarm | d | Read | |||
| Summer State | Read | ||||
| Inlet Temperature Request | °C | Read | |||
| Controlled Temperature | °C | Read | |||
| Room Temperature | °C | Read | |||
| Heat Exchanger Efficiency | % | Read | |||
| Requested Capacity | % | Read | |||
| Actual Capacity | % | Read | |||
| Compressor Type | Read | ||||
| Hot Water Type | Read | ||||
| Hot Water Anode State | Read | ||||
| External Heating Setpoint | °C | Read | |||
| Preheater Block Remaining | s | Read | |||
| DPT In Session | Read | ||||
| DPT Air Flow 1 | m³/h | Read | |||
| DPT Air Flow 2 | m³/h | Read | |||
| DPT Pressure 1 | Pa | Read | |||
| DPT Pressure 2 | Pa | Read | |||
| DPT2 In Session | Read | ||||
| DPT2 Air Flow 1 | m³/h | Read | |||
| DPT2 Air Flow 2 | m³/h | Read | |||
| DPT2 Pressure 1 | Pa | Read | |||
| DPT2 Pressure 2 | Pa | Read | |||
| Bypass Damper | Read | ||||
| After Heating Element | % | Read | |||
| Heat Exchanger De-icing | Read | ||||
| CO2 Sensor Present | Read | ||||
| Stop At Low Room Temperature | Read | ||||
| Last Damper Self-Test | Read | ||||
| Days Since Filter Change | d | Read | |||
| Low Fan Speed At Low Outdoor Temperature | Read | ||||
| Room Temperature Setpoint | °C | Read | |||
| Control Sensor Temperature | °C | Read | |||
| Event Log Alarm Code | Read | ||||
| Event Log Date | Read | ||||
| Event Log Time | Read | ||||
| Event Log T1 Temperature | °C | Read | |||
| Event Log T3 Temperature | °C | Read | |||
| Event Log T4 Temperature | °C | Read | |||
| Event Log T5 Temperature | °C | Read | |||
| Event Log T6 Temperature | °C | Read | |||
| Event Log T7 Temperature | °C | Read | |||
| Event Log T8 Temperature | °C | Read | |||
| Event Log T9 Temperature | °C | Read | |||
| Event Log T10 Temperature | °C | Read | |||
| Event Log T11 Temperature | °C | Read | |||
| Event Log T12 Temperature | °C | Read | |||
| Event Log T13 Temperature | °C | Read | |||
| Event Log T14 Temperature | °C | Read | |||
| Event Log T15 Temperature | °C | Read | |||
| Event Log Digital Inputs 1-8 | Read | ||||
| Event Log Digital Inputs 9-16 | Read | ||||
| Event Log Digital Outputs 1-8 | Read | ||||
| Event Log Digital Outputs 9-16 | Read | ||||
| Event Log Analog Output 1 | % | Read | |||
| Event Log Analog Output 2 | % | Read | |||
| Event Log Analog Output 3 | % | Read | |||
| Event Log Analog Output 4 | % | Read | |||
| Event Log Control State | Read | ||||
| Humidity Average | %RH | Read | |||
| Expansion Board Id | Read | ||||
| Ventilation State | Read | ||||
| Node Address | Read and write | ||||
| Air Flap Output | Read | ||||
| Smoke Flap Output | Read | ||||
| Bypass Flap Open Output | Read | ||||
| Bypass Flap Close Output | Read | ||||
| Air Heat Circulation Pump Output | Read | ||||
| Air Heating Selected Output | Read | ||||
| Air Heater Relay 1 | Read | ||||
| Air Heater Relay 2 | Read | ||||
| Air Heater Relay 3 | Read | ||||
| Compressor Output | Read | ||||
| Compressor 2 Output | Read | ||||
| 4-Way Valve Output | Read | ||||
| Hotgas Valve Heat Output | Read | ||||
| Hotgas Valve Cool Output | Read | ||||
| Air Condenser Active Output | Read | ||||
| Air Condenser Inactive Output | Read | ||||
| Hot Water Heater Output | Read | ||||
| Hot Water 3-Way Valve Output | Read | ||||
| Central Heating Circulation Pump Output | Read | ||||
| Central Heating Relay 1 | Read | ||||
| Central Heating Relay 2 | Read | ||||
| Central Heating Relay 3 | Read | ||||
| External Radiator Heat Output | Read | ||||
| User Function Active Output | Read | ||||
| User Function 2 Active Output | Read | ||||
| Defrost Active Output | Read | ||||
| Alarm Relay Output | Read | ||||
| Preheater Output | Read | ||||
| EHD Or BAH Output | Read | ||||
| Exhaust Fan Speed | % | Read | |||
| Inlet Fan Speed | % | Read | |||
| Air Heater Capacity | % | Read | |||
| Central Heater Capacity | % | Read | |||
| Compressor Capacity | % | Read | |||
| Preheater Capacity | % | Read | |||
| Rotary Heat Exchanger | % | Read | |||
| Clock Second | Read and write | ||||
| Clock Minute | Read and write | ||||
| Clock Hour | Read and write | ||||
| Clock Day | Read and write | ||||
| Clock Month | Read and write | ||||
| Clock Year | Read and write | ||||
| Alarm Reset | Read and write | ||||
| Week Program Select | Read and write | ||||
| User Function Active | Read and write | ||||
| User Function Select | Read and write | ||||
| User Function Period | min | Read and write | |||
| User Function Ventilation Step | Read and write | ||||
| User Function Temperature | °C | Read and write | |||
| User Function Temperature Offset | °C | Read and write | |||
| User Function 2 Active | Read and write | ||||
| User Function 2 Select | Read and write | ||||
| User Function 2 Period | min | Read and write | |||
| User Function 2 Ventilation Step | Read and write | ||||
| User Function 2 Temperature | °C | Read and write | |||
| User Function 2 Temperature Offset | °C | Read and write | |||
| Data Log Interval | min | Read and write | |||
| Machine Type | Read and write | ||||
| On Off Select | Read and write | ||||
| Operation Mode Select | Read and write | ||||
| Ventilation Step Select | Read and write | ||||
| User Temperature Setpoint | °C | Read and write | |||
| Service Mode Select | Read and write | ||||
| Service Mode Capacity | % | Read and write | |||
| Preset Request | Read and write | ||||
| Air Exchange Mode | Read and write | ||||
| Cooling High Ventilation Step | Read and write | ||||
| Damper Test Day | Read and write | ||||
| Last Damper Test Date | Read and write | ||||
| Damper Test State | Read and write | ||||
| Filter Alarm Type | Read and write | ||||
| Cooling Setpoint Select | Read and write | ||||
| Inlet Temperature Min Summer | °C | Read and write | |||
| Inlet Temperature Min Winter | °C | Read and write | |||
| Inlet Temperature Max Summer | °C | Read and write | |||
| Inlet Temperature Max Winter | °C | Read and write | |||
| Summer Winter Limit | °C | Read and write | |||
| Night Cooling Day Temperature | °C | Read and write | |||
| Night Cooling Room Setpoint | °C | Read and write | |||
| Control Sensor Select | Read and write | ||||
| Heat Source Select | Read and write | ||||
| Condenser Low Temperature Curve | °C | Read and write | |||
| Condenser High Temperature Curve | °C | Read and write | |||
| Compressor Start Low Temperature | °C | Read and write | |||
| Compressor Stop Time | Read and write | ||||
| Hot Water Top Setpoint | °C | Read and write | |||
| Hot Water Bottom Setpoint | °C | Read and write | |||
| Hot Water Priority | Read and write | ||||
| Scald Protection Temperature | °C | Read and write | |||
| Hot Water Electric Supplement | Read and write | ||||
| Legionella Day | Read and write | ||||
| Hot Water Bypass Offset | °C | Read and write | |||
| External Heating Offset | °C | Read and write | |||
| Central Heating Select | Read and write | ||||
| Central Heating Supply Min | °C | Read and write | |||
| Central Heating Supply Max | °C | Read and write | |||
| Outdoor Temperature Compensation | °C | Read and write | |||
| Heating Curve Select | Read and write | ||||
| Circulation Pump Mode | Read and write | ||||
| Central Heating Type | Read and write | ||||
| PID Regulation Time | s | Read and write | |||
| Humidity Low Winter Step | Read and write | ||||
| Humidity High Step | Read and write | ||||
| Humidity Limit Low Ventilation | %RH | Read and write | |||
| Humidity High Ventilation Timeout | min | Read and write | |||
| CO2 High Step | Read and write | ||||
| CO2 Limit Normal Ventilation | ppm | Read and write | |||
| CO2 Limit High Ventilation | ppm | Read and write | |||
| User Menu Open | Read and write | ||||
| Panel Language | Read and write | ||||
| Preheater Block | Read and write | ||||
| DPT Calibrate | Read and write | ||||
| DPT2 Calibrate | Read and write | ||||
| Fan Pressure Relation | % | Read and write | |||
| Supply Air P Control | Read and write | ||||
| Supply Air I Control | s | Read and write | |||
| Extract Air P Control | Read and write | ||||
| Extract Air I Control | s | Read and write | |||
| Step 1 Supply Air Flow | m³/h | Read and write | |||
| Step 2 Supply Air Flow | m³/h | Read and write | |||
| Step 3 Supply Air Flow | m³/h | Read and write | |||
| Step 4 Supply Air Flow | m³/h | Read and write | |||
| Step 1 Extract Air Flow | m³/h | Read and write | |||
| Step 2 Extract Air Flow | m³/h | Read and write | |||
| Step 3 Extract Air Flow | m³/h | Read and write | |||
| Step 4 Extract Air Flow | m³/h | Read and write | |||
| Step 1 Supply Air Pressure | Pa | Read and write | |||
| Step 2 Supply Air Pressure | Pa | Read and write | |||
| Step 3 Supply Air Pressure | Pa | Read and write | |||
| Step 4 Supply Air Pressure | Pa | Read and write | |||
| Step 1 Extract Air Pressure | Pa | Read and write | |||
| Step 2 Extract Air Pressure | Pa | Read and write | |||
| Step 3 Extract Air Pressure | Pa | Read and write | |||
| Step 4 Extract Air Pressure | Pa | Read and write | |||
| Room Heating Deadband | °C | Read and write | |||
| High Fan Speed At High Indoor Temperature | Read and write | ||||
| Low Outdoor Temperature Limit | °C | Read and write | |||
| Fan Speed At Low Outdoor Temperature | Read and write | ||||
| Automatic Test Day | Read and write | ||||
| After Heating Type | Read and write | ||||
| After Heat Delay | min | Read and write | |||
| Summer Min Supply Temperature | °C | Read and write | |||
| Summer Max Supply Temperature | °C | Read and write | |||
| Winter Min Supply Temperature | °C | Read and write | |||
| Winter Max Supply Temperature | °C | Read and write | |||
| Room Temperature Deadband | °C | Read and write | |||
| Low Room Temperature Ventilation Reduce | °C | Read and write | |||
| After Heating Activation | Read and write | ||||
| Min Inlet | Read and write | ||||
| Min Exhaust | Read and write | ||||
| Max Exhaust | Read and write | ||||
| Fan Start Delay | Read and write | ||||
| Damper Walking Time | s | Read and write | |||
| Defrost Ventilation Level | Read and write | ||||
| Defrost Bypass Position | Read and write | ||||
| Defrost Block Time | min | Read and write | |||
| Defrost Start Temperature | °C | Read and write | |||
| Defrost Stop Temperature | °C | Read and write | |||
| Defrost Max Duration Compressor | min | Read and write | |||
| Defrost Max Duration Exchanger | min | Read and write | |||
| T6 Min Defrost Time | s | Read and write | |||
| Week Program Edit Index | Read and write | ||||
| Week Program Edit Period | Read and write | ||||
| Week Program Edit Period Next | Read and write | ||||
| Week Program Edit Function | Read and write | ||||
| Week Program Edit Start Time | Read and write | ||||
| Week Program Edit Fan | Read and write | ||||
| Week Program Edit Temperature | °C | Read and write | |||
| Fire Alarm Restart Mode | Read and write | ||||
| Power Save | Read and write | ||||
| Alarm Log Index | Read and write | ||||
| Inlet Fan Scaling | % | Read and write | |||
| Exhaust Fan Scaling | % | Read and write | |||
| Inlet Step 1 Speed | Read and write | ||||
| Inlet Step 2 Speed | Read and write | ||||
| Inlet Step 3 Speed | Read and write | ||||
| Inlet Step 4 Speed | Read and write | ||||
| Exhaust Step 1 Speed | Read and write | ||||
| Exhaust Step 2 Speed | Read and write | ||||
| Exhaust Step 3 Speed | Read and write | ||||
| Exhaust Step 4 Speed | Read and write | ||||
| Air Quality Control Type | Read and write | ||||
| Heater Output Signal Type | Read and write | ||||
| Room Controller Response | Read and write | ||||
| Preheater Defrost Select | Read and write | ||||
| Preheater Defrost Setpoint | Read and write |
Loading registers…
Send your device list
If a device is not in the library yet, we build the template for free as soon as we have the register data.
Use cases
- Show outdoor, supply, exhaust and hot water temperatures of a Nilan unit on one ModbusCloud dashboard.
- Send an email when Alarm Status reports an active alarm or Days To Filter Alarm drops below 7.
- Compare heat exchanger efficiency and compressor capacity over the year in the 365 day history.
- Raise the ventilation step remotely when a resident reports high humidity in the bathroom.
- Lower the hot water setpoint or switch the unit to cooling for the summer from ModbusCloud.
Installation
Switch off the unit and connect RS485 to connector CN7 on the CTS602: pin 2 to A, pin 3 to B and pin 6 to GND.
Wire the other end to the RS485 port of the ModbusCloud Gateway and place a 120 ohm resistor at both ends of the bus.
Check the node address on the panel (default 30); baud rate 19200 and even parity are fixed.
In ModbusCloud, add a Modbus RTU device with address 30, 19200 baud, 8 data bits, even parity and 1 stop bit, and import this template.
Check that T8 Outdoor Temperature and Actual Operation Mode show plausible values.
Things to watch for
The CTS602 does not answer. What should I check?
Check that ModbusCloud uses 19200 baud, even parity and 1 stop bit; the controller cannot be set to anything else. Check the node address (default 30), swap A and B if needed and connect pin 6 GND, because the CTS602 has no opto-isolation and needs a common ground.
Why does a temperature show 2150 instead of 21.5 °C?
The temperatures are sent in hundredths of a degree. The template already divides them by 100; if you added a register by hand, set the scale to 0.01. Temperatures below zero are signed values.
Why can I not write the ventilation step or setpoint?
The CTS602 only accepts writes with function 16, which the template already uses. Writing from ModbusCloud is off per gateway by default and is switched on by request on the control tab. Some settings only work on units with the matching option, such as hot water or central heating.
How do I read older entries of the alarm log?
Write the entry number to Alarm Log Index, then read the Event Log registers for code, date, time, temperatures and outputs of that entry. Date and time are packed in DOS format, so the value needs to be split into year, month, day and time.
More Nilan templates
Want to see how it works?
