Alpha Innotec Heating & Cooling LUX 2.0
Control Alpha Innotec heatpumps via Modbus TCP for heating, cooling, and hot water management.
This ModbusCloud template monitors and controls Alpha Innotec Luxtronic 2.0 heat pump systems over Modbus TCP. It reads outdoor and indoor temperatures, flow and return temperatures, buffer tank top and bottom, warm water tank, heat pump source temperature, operating hours, and system state, and lets you write warm water target temperature, and heating, cooling, and warm water operation modes. Works with SWP, LWD, LWDRX, LW, and LW-A models.
- Protocol
- Modbus TCP
- Connection
- Ethernet, Modbus TCP
- Registers
- 15, read and write
- Brand
- Alpha Innotec
- Key readings
- Outdoor temperature · Flow and return temperatures · Buffer temperatures (top/bottom) · Warm water tank temperature · Heatpump source temperature · Operating hours and system state
- Available commands
- Warm water tank target temperature · Heating operation mode · Cooling operation mode · Warm water operation mode
- Compatible models
- SWP · LWD · LWDRX · LW · LW-A
- Last updated
Registers (15)
14 read, 6 write
| Name | Unit | Access | Address (Hidden until you enter your email) | Function (hidden) | Type (hidden) |
|---|---|---|---|---|---|
| Actual Heatpump Flow temperature [TVL] | °C | Read and write | |||
| Actual Heatpump Return temperature [TRL] | °C | Read | |||
| Acutal Buffer temperature sensor bottom [TRLext] | °C | Read and write | |||
| Actual Warm Water tank temperature [TBW] | °C | Read | |||
| Actual Buffer temperature sensor top [TB2] | °C | Read | |||
| Actual Heatpump Source temperature [TWE] | °C | Read | |||
| State Heatpump Operating Hours | h | Read | |||
| State Heatpump System | Read | ||||
| Actual Outdoor temperature [TA] | °C | Read | |||
| State Warm Water tank Target temperature | °C | Read and write | |||
| State Buffer temperature Target temperature | °C | Read | |||
| State Heating Operation mode | Read and write | ||||
| State Cooling Operation mode | Read and write | ||||
| Actual Flow temperature HC2 [TB1] | °C | Read | |||
| Warm water operation mode | Write |
Loading registers…
Send your device list
If a device is not in the library yet, we build the template for free as soon as we have the register data.
Use cases
- Shift warm water heating to low-tariff hours using a ModbusCloud automation that writes the target temperature on a schedule.
- Track actual COP by plotting electrical power from an Eastron meter alongside thermal output computed from flow and return temperatures.
- Alert when the heat pump source temperature drops close to freezing in a ground-source install.
- Log operating hours to plan compressor service intervals.
- Remotely disable cooling mode during a cold summer week when it accidentally stayed on.
Installation
Purchase the Alpha Connect licensed USB stick from an Alpha Innotec partner and install the Alpha Connect software.
Use Alpha Connect to activate the Modbus TCP server on the Luxtronic 2.0 controller.
Note the Luxtronic IP on the LAN and set a DHCP reservation.
In ModbusCloud, add a Modbus TCP device at the Luxtronic IP, port 502, slave ID 1.
Import the Alpha Innotec template and verify temperatures match the Luxtronic display.
Things to watch for
Modbus TCP port is closed. How do I open it?
You need the Alpha Connect software plus a licensed USB stick from an Alpha Innotec partner. There is no way to enable Modbus TCP from the Luxtronic front panel directly. This is a Alpha Innotec design decision.
Can I use Modbus RTU instead of TCP?
No. The Modbus RTU interface on the Luxtronic 2.0 is reserved for Alpha Innotec service use only and will not respond to third-party requests. Modbus TCP is the only option for ModbusCloud integration.
Some of my Alpha Innotec models cannot cool. Is the template wrong?
Not wrong, the register simply is not used. Heating-only models accept the cooling operation mode write silently but have no effect. Read-side cooling-related values stay at zero. This is expected.
