aqotec RM360 via Modbus TCP

Monitors and controls an aqotec RM360 district heating substation controller via Modbus TCP

Template for the Aqotec RM360 district heating substation controller via Modbus TCP. Reads temperatures, heat meter data, pump statuses, and error bytes. Allows writing setpoints, modes, and corrections for up to four heating circuits and two hot water tanks.

Protocol
Modbus TCP
Connection
Ethernet, Modbus TCP
Registers
98, read and write
Brand
Aqotec
Key readings
Primary and secondary temperatures · Heatmeter energy and power · Heatmeter flowrate and volume · HC1 to HC4 flow and return temperatures · Operating and error status bytes · Pump statuses
Available commands
HC1 to HC4 mode and room setpoint · HC1 to HC4 heating/reduction corrections · Main mode · TC1/TC2 hot water tank mode
Compatible models
RM360
Last updated

Registers (98)

98 read, 29 write

NameUnitAccessAddress (Hidden until you enter your email)Function (hidden)Type (hidden)
sensorvalue T10 outdoor°CRead
sensorvalue T11 prim. return°CRead
sensorvalue T12 sec. flow temperature°CRead
sensorvalue T15 sec. return temperature°CRead
setpoint sec. flow temperature°CRead
calculated primary-valve position%Read
actual used return limitation°CRead
operating statusRead
main modeRead and write
general-correction in reduction modeKRead and write
general-correction in heating modeKRead and write
Error-Byte 1 StatusRead
Error-Byte 2 StatusRead
Error-Byte 3 StatusRead
Error-Byte 4 StatusRead
Heatmeter Energy in kWhkWhRead
Heatmeter actual power in kWkWRead
Heatmeter flowrate in l/hl/hRead
Heatmeter flow temperature°CRead
Heatmeter return temperature°CRead
Heatmeter serial numberRead
Heatmeter volume in m³m³Read
Heatmeter error status (value vom heatmeter)Read
HC1 flow temperature setpoint°CRead
HC1 used room-setpoint°CRead
HC1 sensorvalue T17 return/room°CRead
HC1 status pump (P3)Read
HC1 operating statusRead
HC1 room-setpoint°CRead and write
HC1 outdoor switch-off temperature in heating mode°CRead and write
HC1 outdoor switch-off temperature in reduction mode°CRead and write
HC1 modeRead and write
HC1 correction in heating modeKRead and write
HC1 correction in reduction modeKRead and write
HC2 outdoor switch-off temperature in heating mode°CRead and write
HC2 outdoor switch-off temperature in reduction mode°CRead and write
HC2 modeRead and write
HC2 correction in heating modeKRead and write
HC2 correction in reduction modeKRead and write
HC2 room-setpoint°CRead and write
HC2 status pump (P8)Read
HC2 operating statusRead
HC2 sensorvalue T16 flow temperature°CRead
HC2 flow temperature setpoint°CRead
HC2 sensorvalue T20 return/room°CRead
HC2 used room-setpoint°CRead
HC3 outdoor switch-off temperature in heating mode°CRead and write
HC3 outdoor switch-off temperature in reduction mode°CRead and write
HC3 modeRead and write
HC3 correction in heating modeKRead and write
HC3 correction in reduction modeKRead and write
HC3 room-setpoint°CRead and write
HC3 status pump (3P1)Read
HC3 operating statusRead
HC3 sensorvalue 3TMP flow temperature°CRead
HC3 flow temperature setpoint°CRead
HC3 sensorvalue 3FBT return/room°CRead
HC3 used room-setpoint°CRead
HC4 outdoor switch-off temperature in heating mode°CRead and write
HC4 outdoor switch-off temperature in reduction mode°CRead and write
HC4 modeRead and write
HC4 correction in heating modeKRead and write
HC4 correction in reduction modeKRead and write
HC4 room-setpoint°CRead and write
HC4 status pump (4P1)Read
HC4 operating statusRead
HC4 sensorvalue 4TMP flow temperature°CRead
HC4 flow temperature setpoint°CRead
HC4 sensorvalue 4FBT return/room°CRead
HC4 used room-setpoint°CRead
TC1 operating statusRead
TC1 used setpoint for sensor top°CRead
TC1 sensorvalue T13 top°CRead
TC1 used start temperature for sensor top°CRead
TC1 used setpoint/switchoff temperature for sensor bottom°CRead
TC1 sensorvalue T14 bottom°CRead
TC1 used start temperature for sensor bottom°CRead
TC1 used charging temperature°CRead
TC1 status pump (P4)Read
TC1 mode hot water tankRead and write
HC3 status flow-switch from tapwaterstationRead
HC3 actual flow from tapwater stationl/minRead
TC2 status pump (P5)Read
TC2 setpoint pumpe/valve (AO2)%Read
TC2 sensorvalue T23 top°CRead
TC2 sensorvalue T24 bottom°CRead
TC2 used charging temperature°CRead
TC2 hot water tank used setpoint for sensor top°CRead
TC2 hot water tank used start temperature for sensor top°CRead
TC2 hot water tank used setpoint/switchoff temperature for sensor bottom°CRead
TC2 hot water tank used start temperature for sensor bottom°CRead
TC2 operating status hot water tank<v.>Read
TC2 mode hot water tankRead and write
TC2 used setpoint buffer tank top°CRead
TC2 buffer tank used switchoff temperature botton°CRead
TC2 operating status buffer tankRead
HC7 sensorvalue 7TMP flow temperature°CRead
HC7 sensorvalue 7FBT return/room°CRead

Loading registers…

Send your device list

If a device is not in the library yet, we build the template for free as soon as we have the register data.

Number of installations (optional)

Use cases

  • Monitor primary and secondary temperatures of a district heating substation on a live cloud dashboard.
  • Adjust room temperature setpoints and heating corrections for all four heating circuits remotely.
  • Create an alert when an error status byte indicates a fault condition on the RM360 controller.
  • Log heat meter energy and flow rate data over time to verify district heating consumption.
  • Switch the main operating mode or hot water tank modes for TC1 and TC2 without an on-site visit.
  • Compare flow and return temperatures across heating circuits to detect balancing issues.

Installation

  1. Connect the Aqotec RM360 to your local network via its Ethernet port and verify that Modbus TCP is enabled in the controller settings.

  2. Connect your ModbusCloud Gateway to the same local network, ensuring it can reach the RM360 IP address on the configured Modbus TCP port.

  3. Note the IP address and Modbus TCP port of the RM360, and configure these in the ModbusCloud gateway settings.

  4. Import the Aqotec RM360 Modbus TCP template from the ModbusCloud template library into your project.

  5. Verify communication by checking that temperature readings and status values appear correctly on the ModbusCloud dashboard.

  6. Test write access by adjusting a heating circuit setpoint and confirming the change is reflected on the RM360 controller display.

Things to watch for

Why do some temperature values appear as incorrect or very large numbers?

The RM360 uses float32 registers that span two consecutive Modbus addresses. Ensure the byte order and word order settings in the gateway match the RM360 configuration. The template is preconfigured for the correct data types, but custom modifications may introduce errors.

Which Modbus TCP port does the RM360 use?

The default Modbus TCP port is typically 502. Verify this in the RM360 network settings. If a different port has been configured, update the gateway connection settings accordingly.

Can I use this template if I only have two heating circuits installed?

Yes. The template includes registers for HC1 through HC4 and both hot water tanks. Unused circuits will simply return zero or default values. You can hide unused registers in your ModbusCloud dashboard.

Do I need a specific firmware version on the RM360 for Modbus TCP to work?

Modbus TCP support depends on the RM360 firmware and hardware revision. Check the Aqotec documentation or contact Aqotec support to confirm your unit supports Modbus TCP communication.
