Buderus Logamatic 5000
Controller for commercial boilers and cascades with heating circuits, hot water and heat demand over Modbus TCP.
The Buderus Logamatic 5313 and 5311 are Logamatic 5000 controllers that run commercial floor-standing boilers, boiler cascades and heating circuits in large buildings, industry and greenhouse boiler houses. This Modbus TCP template reads temperatures, boiler output, pressure, fault codes and operating states and writes flow temperature or output demand, setpoints and operating modes from ModbusCloud.
- Protocol
- Modbus TCP
- Connection
- Ethernet, Modbus TCP
- Registers
- 893, read and write
- Brand
- Buderus
- Key readings
- System flow and return temperature · Outdoor temperature · Boiler flow and return temperature · Boiler output, pressure and flue gas · Heating circuit temperatures · Hot water temperature · Fault codes and HMI status · Cascade output
- Available commands
- Flow temperature demand · Output demand · Room temperature setpoints · Hot water setpoints · Auto and manual operating modes · Buffer charging settings
- Compatible models
- Logamatic 5313 · Logamatic 5311 · Bosch Control 8313 · Bosch Control 8311
- Last updated
Registers (893)
893 read, 122 write
| Name | Unit | Access | Address (Hidden until you enter your email) | Function (hidden) | Type (hidden) |
|---|---|---|---|---|---|
| System Outdoor Temperature | °C | Read | |||
| System Damped Outdoor Temperature | °C | Read | |||
| System Flow Temperature | °C | Read | |||
| System HMI Status | Read | ||||
| Strategy Return Temperature | °C | Read | |||
| Strategy System Flow / Header Temperature | °C | Read | |||
| Strategy HMI Status | Read | ||||
| Strategy Actual Output | % | Read | |||
| Strategy Energy Source | Read | ||||
| Strategy Header Temperature Raise | °C | Read | |||
| Strategy Heat Demand Source | Read | ||||
| Strategy Flow Setpoint | °C | Read | |||
| Strategy Output Setpoint | % | Read | |||
| Strategy Operating Mode | Read | ||||
| Strategy Status Bits | Read | ||||
| Strategy Max Requested Flow Temperature | °C | Read | |||
| Energy Data Heat Output | kW | Read | |||
| Energy Data Gas Consumption Hi | kW | Read | |||
| Energy Data Electrical Power | W | Read | |||
| Cascade Boilers Active | Read | ||||
| Cascade Boilers Under Control | Read | ||||
| Cascade Boilers Released | Read | ||||
| Cascade Total Output | kW | Read | |||
| Cascade Output Under Control | kW | Read | |||
| Cascade Actual Output | kW | Read | |||
| Cascade HMI Status | Read | ||||
| Cascade Current Demand Mode | Read | ||||
| Cascade Buffer Charging Output Demand | % | Read | |||
| Cascade Buffer Charging Setpoint | °C | Read | |||
| Cascade Buffer Charging Min Modulation | % | Read | |||
| Cascade Auto Buffer Charging On Limit | °C | Read | |||
| Cascade Auto Buffer Charging Off Limit | °C | Read | |||
| Cascade Status Bits | Read | ||||
| Boiler 1 Type | Read | ||||
| Boiler 1 Flow Temperature | °C | Read | |||
| Boiler 1 Flow Temperature Rate | Read | ||||
| Boiler 1 Return Temperature | °C | Read | |||
| Boiler 1 Actual Output | % | Read | |||
| Boiler 1 Load Limitation | % | Read | |||
| Boiler 1 Operating Temperature | °C | Read | |||
| Boiler 1 Max Output | kW | Read | |||
| Boiler 1 Min Output | % | Read | |||
| Boiler 1 Burner Type | Read | ||||
| Boiler 1 Fuel Type | Read | ||||
| Boiler 1 Max Flow Temperature | °C | Read | |||
| Boiler 1 HMI Status | Read | ||||
| Boiler 1 Status Bits | Read | ||||
| Boiler 1 Requested Mode | Read | ||||
| Boiler 1 Requested Setpoint | °C | Read | |||
| Boiler 1 Output Setpoint | % | Read | |||
| Boiler 1 Pressure | bar | Read | |||
| Boiler 1 Fault Code | Read | ||||
| Boiler 1 Display Code | Read | ||||
| Boiler 1 Cascade Start Index | Read | ||||
| Boiler 1 Starts | Read | ||||
| Boiler 1 Operating Time | min | Read | |||
| Boiler 1 Valve Position | % | Read | |||
| Boiler 1 Pump Modulation | % | Read | |||
| Boiler 1 STB Temperature | °C | Read | |||
| Boiler 1 Flue Gas Temperature | °C | Read | |||
| Boiler 2 Type | Read | ||||
| Boiler 2 Flow Temperature | °C | Read | |||
| Boiler 2 Flow Temperature Rate | Read | ||||
| Boiler 2 Return Temperature | °C | Read | |||
| Boiler 2 Actual Output | % | Read | |||
| Boiler 2 Load Limitation | % | Read | |||
| Boiler 2 Operating Temperature | °C | Read | |||
| Boiler 2 Max Output | kW | Read | |||
| Boiler 2 Min Output | % | Read | |||
| Boiler 2 Burner Type | Read | ||||
| Boiler 2 Fuel Type | Read | ||||
| Boiler 2 Max Flow Temperature | °C | Read | |||
| Boiler 2 HMI Status | Read | ||||
| Boiler 2 Status Bits | Read | ||||
| Boiler 2 Requested Mode | Read | ||||
| Boiler 2 Requested Setpoint | °C | Read | |||
| Boiler 2 Output Setpoint | % | Read | |||
| Boiler 2 Pressure | bar | Read | |||
| Boiler 2 Fault Code | Read | ||||
| Boiler 2 Display Code | Read | ||||
| Boiler 2 Cascade Start Index | Read | ||||
| Boiler 2 Starts | Read | ||||
| Boiler 2 Operating Time | min | Read | |||
| Boiler 2 Valve Position | % | Read | |||
| Boiler 2 Pump Modulation | % | Read | |||
| Boiler 2 STB Temperature | °C | Read | |||
| Boiler 2 Flue Gas Temperature | °C | Read | |||
| Boiler 3 Type | Read | ||||
| Boiler 3 Flow Temperature | °C | Read | |||
| Boiler 3 Flow Temperature Rate | Read | ||||
| Boiler 3 Return Temperature | °C | Read | |||
| Boiler 3 Actual Output | % | Read | |||
| Boiler 3 Load Limitation | % | Read | |||
| Boiler 3 Operating Temperature | °C | Read | |||
| Boiler 3 Max Output | kW | Read | |||
| Boiler 3 Min Output | % | Read | |||
| Boiler 3 Burner Type | Read | ||||
| Boiler 3 Fuel Type | Read | ||||
| Boiler 3 Max Flow Temperature | °C | Read | |||
| Boiler 3 HMI Status | Read | ||||
| Boiler 3 Status Bits | Read | ||||
| Boiler 3 Requested Mode | Read | ||||
| Boiler 3 Requested Setpoint | °C | Read | |||
| Boiler 3 Output Setpoint | % | Read | |||
| Boiler 3 Pressure | bar | Read | |||
| Boiler 3 Fault Code | Read | ||||
| Boiler 3 Display Code | Read | ||||
| Boiler 3 Cascade Start Index | Read | ||||
| Boiler 3 Starts | Read | ||||
| Boiler 3 Operating Time | min | Read | |||
| Boiler 3 Valve Position | % | Read | |||
| Boiler 3 Pump Modulation | % | Read | |||
| Boiler 3 STB Temperature | °C | Read | |||
| Boiler 3 Flue Gas Temperature | °C | Read | |||
| Boiler 4 Type | Read | ||||
| Boiler 4 Flow Temperature | °C | Read | |||
| Boiler 4 Flow Temperature Rate | Read | ||||
| Boiler 4 Return Temperature | °C | Read | |||
| Boiler 4 Actual Output | % | Read | |||
| Boiler 4 Load Limitation | % | Read | |||
| Boiler 4 Operating Temperature | °C | Read | |||
| Boiler 4 Max Output | kW | Read | |||
| Boiler 4 Min Output | % | Read | |||
| Boiler 4 Burner Type | Read | ||||
| Boiler 4 Fuel Type | Read | ||||
| Boiler 4 Max Flow Temperature | °C | Read | |||
| Boiler 4 HMI Status | Read | ||||
| Boiler 4 Status Bits | Read | ||||
| Boiler 4 Requested Mode | Read | ||||
| Boiler 4 Requested Setpoint | °C | Read | |||
| Boiler 4 Output Setpoint | % | Read | |||
| Boiler 4 Pressure | bar | Read | |||
| Boiler 4 Fault Code | Read | ||||
| Boiler 4 Display Code | Read | ||||
| Boiler 4 Cascade Start Index | Read | ||||
| Boiler 4 Starts | Read | ||||
| Boiler 4 Operating Time | min | Read | |||
| Boiler 4 Valve Position | % | Read | |||
| Boiler 4 Pump Modulation | % | Read | |||
| Boiler 4 STB Temperature | °C | Read | |||
| Boiler 4 Flue Gas Temperature | °C | Read | |||
| Boiler 5 Type | Read | ||||
| Boiler 5 Flow Temperature | °C | Read | |||
| Boiler 5 Flow Temperature Rate | Read | ||||
| Boiler 5 Return Temperature | °C | Read | |||
| Boiler 5 Actual Output | % | Read | |||
| Boiler 5 Load Limitation | % | Read | |||
| Boiler 5 Operating Temperature | °C | Read | |||
| Boiler 5 Max Output | kW | Read | |||
| Boiler 5 Min Output | % | Read | |||
| Boiler 5 Burner Type | Read | ||||
| Boiler 5 Fuel Type | Read | ||||
| Boiler 5 Max Flow Temperature | °C | Read | |||
| Boiler 5 HMI Status | Read | ||||
| Boiler 5 Status Bits | Read | ||||
| Boiler 5 Requested Mode | Read | ||||
| Boiler 5 Requested Setpoint | °C | Read | |||
| Boiler 5 Output Setpoint | % | Read | |||
| Boiler 5 Pressure | bar | Read | |||
| Boiler 5 Fault Code | Read | ||||
| Boiler 5 Display Code | Read | ||||
| Boiler 5 Cascade Start Index | Read | ||||
| Boiler 5 Starts | Read | ||||
| Boiler 5 Operating Time | min | Read | |||
| Boiler 5 Valve Position | % | Read | |||
| Boiler 5 Pump Modulation | % | Read | |||
| Boiler 5 STB Temperature | °C | Read | |||
| Boiler 5 Flue Gas Temperature | °C | Read | |||
| Boiler 6 Type | Read | ||||
| Boiler 6 Flow Temperature | °C | Read | |||
| Boiler 6 Flow Temperature Rate | Read | ||||
| Boiler 6 Return Temperature | °C | Read | |||
| Boiler 6 Actual Output | % | Read | |||
| Boiler 6 Load Limitation | % | Read | |||
| Boiler 6 Operating Temperature | °C | Read | |||
| Boiler 6 Max Output | kW | Read | |||
| Boiler 6 Min Output | % | Read | |||
| Boiler 6 Burner Type | Read | ||||
| Boiler 6 Fuel Type | Read | ||||
| Boiler 6 Max Flow Temperature | °C | Read | |||
| Boiler 6 HMI Status | Read | ||||
| Boiler 6 Status Bits | Read | ||||
| Boiler 6 Requested Mode | Read | ||||
| Boiler 6 Requested Setpoint | °C | Read | |||
| Boiler 6 Output Setpoint | % | Read | |||
| Boiler 6 Pressure | bar | Read | |||
| Boiler 6 Fault Code | Read | ||||
| Boiler 6 Display Code | Read | ||||
| Boiler 6 Cascade Start Index | Read | ||||
| Boiler 6 Starts | Read | ||||
| Boiler 6 Operating Time | min | Read | |||
| Boiler 6 Valve Position | % | Read | |||
| Boiler 6 Pump Modulation | % | Read | |||
| Boiler 6 STB Temperature | °C | Read | |||
| Boiler 6 Flue Gas Temperature | °C | Read | |||
| Boiler 7 Type | Read | ||||
| Boiler 7 Flow Temperature | °C | Read | |||
| Boiler 7 Flow Temperature Rate | Read | ||||
| Boiler 7 Return Temperature | °C | Read | |||
| Boiler 7 Actual Output | % | Read | |||
| Boiler 7 Load Limitation | % | Read | |||
| Boiler 7 Operating Temperature | °C | Read | |||
| Boiler 7 Max Output | kW | Read | |||
| Boiler 7 Min Output | % | Read | |||
| Boiler 7 Burner Type | Read | ||||
| Boiler 7 Fuel Type | Read | ||||
| Boiler 7 Max Flow Temperature | °C | Read | |||
| Boiler 7 HMI Status | Read | ||||
| Boiler 7 Status Bits | Read | ||||
| Boiler 7 Requested Mode | Read | ||||
| Boiler 7 Requested Setpoint | °C | Read | |||
| Boiler 7 Output Setpoint | % | Read | |||
| Boiler 7 Pressure | bar | Read | |||
| Boiler 7 Fault Code | Read | ||||
| Boiler 7 Display Code | Read | ||||
| Boiler 7 Cascade Start Index | Read | ||||
| Boiler 7 Starts | Read | ||||
| Boiler 7 Operating Time | min | Read | |||
| Boiler 7 Valve Position | % | Read | |||
| Boiler 7 Pump Modulation | % | Read | |||
| Boiler 7 STB Temperature | °C | Read | |||
| Boiler 7 Flue Gas Temperature | °C | Read | |||
| Boiler 8 Type | Read | ||||
| Boiler 8 Flow Temperature | °C | Read | |||
| Boiler 8 Flow Temperature Rate | Read | ||||
| Boiler 8 Return Temperature | °C | Read | |||
| Boiler 8 Actual Output | % | Read | |||
| Boiler 8 Load Limitation | % | Read | |||
| Boiler 8 Operating Temperature | °C | Read | |||
| Boiler 8 Max Output | kW | Read | |||
| Boiler 8 Min Output | % | Read | |||
| Boiler 8 Burner Type | Read | ||||
| Boiler 8 Fuel Type | Read | ||||
| Boiler 8 Max Flow Temperature | °C | Read | |||
| Boiler 8 HMI Status | Read | ||||
| Boiler 8 Status Bits | Read | ||||
| Boiler 8 Requested Mode | Read | ||||
| Boiler 8 Requested Setpoint | °C | Read | |||
| Boiler 8 Output Setpoint | % | Read | |||
| Boiler 8 Pressure | bar | Read | |||
| Boiler 8 Fault Code | Read | ||||
| Boiler 8 Display Code | Read | ||||
| Boiler 8 Cascade Start Index | Read | ||||
| Boiler 8 Starts | Read | ||||
| Boiler 8 Operating Time | min | Read | |||
| Boiler 8 Valve Position | % | Read | |||
| Boiler 8 Pump Modulation | % | Read | |||
| Boiler 8 STB Temperature | °C | Read | |||
| Boiler 8 Flue Gas Temperature | °C | Read | |||
| Boiler 9 Type | Read | ||||
| Boiler 9 Flow Temperature | °C | Read | |||
| Boiler 9 Flow Temperature Rate | Read | ||||
| Boiler 9 Return Temperature | °C | Read | |||
| Boiler 9 Actual Output | % | Read | |||
| Boiler 9 Load Limitation | % | Read | |||
| Boiler 9 Operating Temperature | °C | Read | |||
| Boiler 9 Max Output | kW | Read | |||
| Boiler 9 Min Output | % | Read | |||
| Boiler 9 Burner Type | Read | ||||
| Boiler 9 Fuel Type | Read | ||||
| Boiler 9 Max Flow Temperature | °C | Read | |||
| Boiler 9 HMI Status | Read | ||||
| Boiler 9 Status Bits | Read | ||||
| Boiler 9 Requested Mode | Read | ||||
| Boiler 9 Requested Setpoint | °C | Read | |||
| Boiler 9 Output Setpoint | % | Read | |||
| Boiler 9 Pressure | bar | Read | |||
| Boiler 9 Fault Code | Read | ||||
| Boiler 9 Display Code | Read | ||||
| Boiler 9 Cascade Start Index | Read | ||||
| Boiler 9 Starts | Read | ||||
| Boiler 9 Operating Time | min | Read | |||
| Boiler 9 Valve Position | % | Read | |||
| Boiler 9 Pump Modulation | % | Read | |||
| Boiler 9 STB Temperature | °C | Read | |||
| Boiler 9 Flue Gas Temperature | °C | Read | |||
| Boiler 10 Type | Read | ||||
| Boiler 10 Flow Temperature | °C | Read | |||
| Boiler 10 Flow Temperature Rate | Read | ||||
| Boiler 10 Return Temperature | °C | Read | |||
| Boiler 10 Actual Output | % | Read | |||
| Boiler 10 Load Limitation | % | Read | |||
| Boiler 10 Operating Temperature | °C | Read | |||
| Boiler 10 Max Output | kW | Read | |||
| Boiler 10 Min Output | % | Read | |||
| Boiler 10 Burner Type | Read | ||||
| Boiler 10 Fuel Type | Read | ||||
| Boiler 10 Max Flow Temperature | °C | Read | |||
| Boiler 10 HMI Status | Read | ||||
| Boiler 10 Status Bits | Read | ||||
| Boiler 10 Requested Mode | Read | ||||
| Boiler 10 Requested Setpoint | °C | Read | |||
| Boiler 10 Output Setpoint | % | Read | |||
| Boiler 10 Pressure | bar | Read | |||
| Boiler 10 Fault Code | Read | ||||
| Boiler 10 Display Code | Read | ||||
| Boiler 10 Cascade Start Index | Read | ||||
| Boiler 10 Starts | Read | ||||
| Boiler 10 Operating Time | min | Read | |||
| Boiler 10 Valve Position | % | Read | |||
| Boiler 10 Pump Modulation | % | Read | |||
| Boiler 10 STB Temperature | °C | Read | |||
| Boiler 10 Flue Gas Temperature | °C | Read | |||
| Boiler 11 Type | Read | ||||
| Boiler 11 Flow Temperature | °C | Read | |||
| Boiler 11 Flow Temperature Rate | Read | ||||
| Boiler 11 Return Temperature | °C | Read | |||
| Boiler 11 Actual Output | % | Read | |||
| Boiler 11 Load Limitation | % | Read | |||
| Boiler 11 Operating Temperature | °C | Read | |||
| Boiler 11 Max Output | kW | Read | |||
| Boiler 11 Min Output | % | Read | |||
| Boiler 11 Burner Type | Read | ||||
| Boiler 11 Fuel Type | Read | ||||
| Boiler 11 Max Flow Temperature | °C | Read | |||
| Boiler 11 HMI Status | Read | ||||
| Boiler 11 Status Bits | Read | ||||
| Boiler 11 Requested Mode | Read | ||||
| Boiler 11 Requested Setpoint | °C | Read | |||
| Boiler 11 Output Setpoint | % | Read | |||
| Boiler 11 Pressure | bar | Read | |||
| Boiler 11 Fault Code | Read | ||||
| Boiler 11 Display Code | Read | ||||
| Boiler 11 Cascade Start Index | Read | ||||
| Boiler 11 Starts | Read | ||||
| Boiler 11 Operating Time | min | Read | |||
| Boiler 11 Valve Position | % | Read | |||
| Boiler 11 Pump Modulation | % | Read | |||
| Boiler 11 STB Temperature | °C | Read | |||
| Boiler 11 Flue Gas Temperature | °C | Read | |||
| Boiler 12 Type | Read | ||||
| Boiler 12 Flow Temperature | °C | Read | |||
| Boiler 12 Flow Temperature Rate | Read | ||||
| Boiler 12 Return Temperature | °C | Read | |||
| Boiler 12 Actual Output | % | Read | |||
| Boiler 12 Load Limitation | % | Read | |||
| Boiler 12 Operating Temperature | °C | Read | |||
| Boiler 12 Max Output | kW | Read | |||
| Boiler 12 Min Output | % | Read | |||
| Boiler 12 Burner Type | Read | ||||
| Boiler 12 Fuel Type | Read | ||||
| Boiler 12 Max Flow Temperature | °C | Read | |||
| Boiler 12 HMI Status | Read | ||||
| Boiler 12 Status Bits | Read | ||||
| Boiler 12 Requested Mode | Read | ||||
| Boiler 12 Requested Setpoint | °C | Read | |||
| Boiler 12 Output Setpoint | % | Read | |||
| Boiler 12 Pressure | bar | Read | |||
| Boiler 12 Fault Code | Read | ||||
| Boiler 12 Display Code | Read | ||||
| Boiler 12 Cascade Start Index | Read | ||||
| Boiler 12 Starts | Read | ||||
| Boiler 12 Operating Time | min | Read | |||
| Boiler 12 Valve Position | % | Read | |||
| Boiler 12 Pump Modulation | % | Read | |||
| Boiler 12 STB Temperature | °C | Read | |||
| Boiler 12 Flue Gas Temperature | °C | Read | |||
| Boiler 13 Type | Read | ||||
| Boiler 13 Flow Temperature | °C | Read | |||
| Boiler 13 Flow Temperature Rate | Read | ||||
| Boiler 13 Return Temperature | °C | Read | |||
| Boiler 13 Actual Output | % | Read | |||
| Boiler 13 Load Limitation | % | Read | |||
| Boiler 13 Operating Temperature | °C | Read | |||
| Boiler 13 Max Output | kW | Read | |||
| Boiler 13 Min Output | % | Read | |||
| Boiler 13 Burner Type | Read | ||||
| Boiler 13 Fuel Type | Read | ||||
| Boiler 13 Max Flow Temperature | °C | Read | |||
| Boiler 13 HMI Status | Read | ||||
| Boiler 13 Status Bits | Read | ||||
| Boiler 13 Requested Mode | Read | ||||
| Boiler 13 Requested Setpoint | °C | Read | |||
| Boiler 13 Output Setpoint | % | Read | |||
| Boiler 13 Pressure | bar | Read | |||
| Boiler 13 Fault Code | Read | ||||
| Boiler 13 Display Code | Read | ||||
| Boiler 13 Cascade Start Index | Read | ||||
| Boiler 13 Starts | Read | ||||
| Boiler 13 Operating Time | min | Read | |||
| Boiler 13 Valve Position | % | Read | |||
| Boiler 13 Pump Modulation | % | Read | |||
| Boiler 13 STB Temperature | °C | Read | |||
| Boiler 13 Flue Gas Temperature | °C | Read | |||
| Boiler 14 Type | Read | ||||
| Boiler 14 Flow Temperature | °C | Read | |||
| Boiler 14 Flow Temperature Rate | Read | ||||
| Boiler 14 Return Temperature | °C | Read | |||
| Boiler 14 Actual Output | % | Read | |||
| Boiler 14 Load Limitation | % | Read | |||
| Boiler 14 Operating Temperature | °C | Read | |||
| Boiler 14 Max Output | kW | Read | |||
| Boiler 14 Min Output | % | Read | |||
| Boiler 14 Burner Type | Read | ||||
| Boiler 14 Fuel Type | Read | ||||
| Boiler 14 Max Flow Temperature | °C | Read | |||
| Boiler 14 HMI Status | Read | ||||
| Boiler 14 Status Bits | Read | ||||
| Boiler 14 Requested Mode | Read | ||||
| Boiler 14 Requested Setpoint | °C | Read | |||
| Boiler 14 Output Setpoint | % | Read | |||
| Boiler 14 Pressure | bar | Read | |||
| Boiler 14 Fault Code | Read | ||||
| Boiler 14 Display Code | Read | ||||
| Boiler 14 Cascade Start Index | Read | ||||
| Boiler 14 Starts | Read | ||||
| Boiler 14 Operating Time | min | Read | |||
| Boiler 14 Valve Position | % | Read | |||
| Boiler 14 Pump Modulation | % | Read | |||
| Boiler 14 STB Temperature | °C | Read | |||
| Boiler 14 Flue Gas Temperature | °C | Read | |||
| Boiler 15 Type | Read | ||||
| Boiler 15 Flow Temperature | °C | Read | |||
| Boiler 15 Flow Temperature Rate | Read | ||||
| Boiler 15 Return Temperature | °C | Read | |||
| Boiler 15 Actual Output | % | Read | |||
| Boiler 15 Load Limitation | % | Read | |||
| Boiler 15 Operating Temperature | °C | Read | |||
| Boiler 15 Max Output | kW | Read | |||
| Boiler 15 Min Output | % | Read | |||
| Boiler 15 Burner Type | Read | ||||
| Boiler 15 Fuel Type | Read | ||||
| Boiler 15 Max Flow Temperature | °C | Read | |||
| Boiler 15 HMI Status | Read | ||||
| Boiler 15 Status Bits | Read | ||||
| Boiler 15 Requested Mode | Read | ||||
| Boiler 15 Requested Setpoint | °C | Read | |||
| Boiler 15 Output Setpoint | % | Read | |||
| Boiler 15 Pressure | bar | Read | |||
| Boiler 15 Fault Code | Read | ||||
| Boiler 15 Display Code | Read | ||||
| Boiler 15 Cascade Start Index | Read | ||||
| Boiler 15 Starts | Read | ||||
| Boiler 15 Operating Time | min | Read | |||
| Boiler 15 Valve Position | % | Read | |||
| Boiler 15 Pump Modulation | % | Read | |||
| Boiler 15 STB Temperature | °C | Read | |||
| Boiler 15 Flue Gas Temperature | °C | Read | |||
| Boiler 16 Type | Read | ||||
| Boiler 16 Flow Temperature | °C | Read | |||
| Boiler 16 Flow Temperature Rate | Read | ||||
| Boiler 16 Return Temperature | °C | Read | |||
| Boiler 16 Actual Output | % | Read | |||
| Boiler 16 Load Limitation | % | Read | |||
| Boiler 16 Operating Temperature | °C | Read | |||
| Boiler 16 Max Output | kW | Read | |||
| Boiler 16 Min Output | % | Read | |||
| Boiler 16 Burner Type | Read | ||||
| Boiler 16 Fuel Type | Read | ||||
| Boiler 16 Max Flow Temperature | °C | Read | |||
| Boiler 16 HMI Status | Read | ||||
| Boiler 16 Status Bits | Read | ||||
| Boiler 16 Requested Mode | Read | ||||
| Boiler 16 Requested Setpoint | °C | Read | |||
| Boiler 16 Output Setpoint | % | Read | |||
| Boiler 16 Pressure | bar | Read | |||
| Boiler 16 Fault Code | Read | ||||
| Boiler 16 Display Code | Read | ||||
| Boiler 16 Cascade Start Index | Read | ||||
| Boiler 16 Starts | Read | ||||
| Boiler 16 Operating Time | min | Read | |||
| Boiler 16 Valve Position | % | Read | |||
| Boiler 16 Pump Modulation | % | Read | |||
| Boiler 16 STB Temperature | °C | Read | |||
| Boiler 16 Flue Gas Temperature | °C | Read | |||
| Heating Circuit 00 Room Temperature Setpoint | °C | Read | |||
| Heating Circuit 00 Room Temperature | °C | Read | |||
| Heating Circuit 00 Flow Temperature Setpoint | °C | Read | |||
| Heating Circuit 00 Flow Temperature | °C | Read | |||
| Heating Circuit 00 Actuator Modulation | % | Read | |||
| Heating Circuit 00 Pump Modulation | % | Read | |||
| Heating Circuit 00 Current Operating Mode | Read | ||||
| Heating Circuit 00 HMI Status | Read | ||||
| Heating Circuit 00 Hydraulic Status | Read | ||||
| Heating Circuit 01 Room Temperature Setpoint | °C | Read | |||
| Heating Circuit 01 Room Temperature | °C | Read | |||
| Heating Circuit 01 Flow Temperature Setpoint | °C | Read | |||
| Heating Circuit 01 Flow Temperature | °C | Read | |||
| Heating Circuit 01 Actuator Modulation | % | Read | |||
| Heating Circuit 01 Pump Modulation | % | Read | |||
| Heating Circuit 01 Current Operating Mode | Read | ||||
| Heating Circuit 01 HMI Status | Read | ||||
| Heating Circuit 01 Hydraulic Status | Read | ||||
| Heating Circuit 02 Room Temperature Setpoint | °C | Read | |||
| Heating Circuit 02 Room Temperature | °C | Read | |||
| Heating Circuit 02 Flow Temperature Setpoint | °C | Read | |||
| Heating Circuit 02 Flow Temperature | °C | Read | |||
| Heating Circuit 02 Actuator Modulation | % | Read | |||
| Heating Circuit 02 Pump Modulation | % | Read | |||
| Heating Circuit 02 Current Operating Mode | Read | ||||
| Heating Circuit 02 HMI Status | Read | ||||
| Heating Circuit 02 Hydraulic Status | Read | ||||
| Heating Circuit 03 Room Temperature Setpoint | °C | Read | |||
| Heating Circuit 03 Room Temperature | °C | Read | |||
| Heating Circuit 03 Flow Temperature Setpoint | °C | Read | |||
| Heating Circuit 03 Flow Temperature | °C | Read | |||
| Heating Circuit 03 Actuator Modulation | % | Read | |||
| Heating Circuit 03 Pump Modulation | % | Read | |||
| Heating Circuit 03 Current Operating Mode | Read | ||||
| Heating Circuit 03 HMI Status | Read | ||||
| Heating Circuit 03 Hydraulic Status | Read | ||||
| Heating Circuit 04 Room Temperature Setpoint | °C | Read | |||
| Heating Circuit 04 Room Temperature | °C | Read | |||
| Heating Circuit 04 Flow Temperature Setpoint | °C | Read | |||
| Heating Circuit 04 Flow Temperature | °C | Read | |||
| Heating Circuit 04 Actuator Modulation | % | Read | |||
| Heating Circuit 04 Pump Modulation | % | Read | |||
| Heating Circuit 04 Current Operating Mode | Read | ||||
| Heating Circuit 04 HMI Status | Read | ||||
| Heating Circuit 04 Hydraulic Status | Read | ||||
| Heating Circuit 05 Room Temperature Setpoint | °C | Read | |||
| Heating Circuit 05 Room Temperature | °C | Read | |||
| Heating Circuit 05 Flow Temperature Setpoint | °C | Read | |||
| Heating Circuit 05 Flow Temperature | °C | Read | |||
| Heating Circuit 05 Actuator Modulation | % | Read | |||
| Heating Circuit 05 Pump Modulation | % | Read | |||
| Heating Circuit 05 Current Operating Mode | Read | ||||
| Heating Circuit 05 HMI Status | Read | ||||
| Heating Circuit 05 Hydraulic Status | Read | ||||
| Heating Circuit 06 Room Temperature Setpoint | °C | Read | |||
| Heating Circuit 06 Room Temperature | °C | Read | |||
| Heating Circuit 06 Flow Temperature Setpoint | °C | Read | |||
| Heating Circuit 06 Flow Temperature | °C | Read | |||
| Heating Circuit 06 Actuator Modulation | % | Read | |||
| Heating Circuit 06 Pump Modulation | % | Read | |||
| Heating Circuit 06 Current Operating Mode | Read | ||||
| Heating Circuit 06 HMI Status | Read | ||||
| Heating Circuit 06 Hydraulic Status | Read | ||||
| Heating Circuit 07 Room Temperature Setpoint | °C | Read | |||
| Heating Circuit 07 Room Temperature | °C | Read | |||
| Heating Circuit 07 Flow Temperature Setpoint | °C | Read | |||
| Heating Circuit 07 Flow Temperature | °C | Read | |||
| Heating Circuit 07 Actuator Modulation | % | Read | |||
| Heating Circuit 07 Pump Modulation | % | Read | |||
| Heating Circuit 07 Current Operating Mode | Read | ||||
| Heating Circuit 07 HMI Status | Read | ||||
| Heating Circuit 07 Hydraulic Status | Read | ||||
| Heating Circuit 08 Room Temperature Setpoint | °C | Read | |||
| Heating Circuit 08 Room Temperature | °C | Read | |||
| Heating Circuit 08 Flow Temperature Setpoint | °C | Read | |||
| Heating Circuit 08 Flow Temperature | °C | Read | |||
| Heating Circuit 08 Actuator Modulation | % | Read | |||
| Heating Circuit 08 Pump Modulation | % | Read | |||
| Heating Circuit 08 Current Operating Mode | Read | ||||
| Heating Circuit 08 HMI Status | Read | ||||
| Heating Circuit 08 Hydraulic Status | Read | ||||
| DHW 1 Charge Pump Status | Read | ||||
| DHW 1 Circulation Pump Status | Read | ||||
| DHW 1 Hydraulic Status | Read | ||||
| DHW 1 Thermal Disinfection Status | Read | ||||
| DHW 1 HMI Status | Read | ||||
| DHW 1 Temperature Setpoint | °C | Read | |||
| DHW 1 Temperature | °C | Read | |||
| DHW 2 Charge Pump Status | Read | ||||
| DHW 2 Circulation Pump Status | Read | ||||
| DHW 2 Hydraulic Status | Read | ||||
| DHW 2 Thermal Disinfection Status | Read | ||||
| DHW 2 HMI Status | Read | ||||
| DHW 2 Temperature Setpoint | °C | Read | |||
| DHW 2 Temperature | °C | Read | |||
| Fresh Water Station DHW Temperature | °C | Read | |||
| Fresh Water Station DHW Flow | l/min | Read | |||
| Fresh Water Station Buffer Flow Temperature | °C | Read | |||
| Fresh Water Station Cold Water Temperature | °C | Read | |||
| Fresh Water Station Primary Pump | % | Read | |||
| Fresh Water Station DHW Setpoint | °C | Read | |||
| Fresh Water Station DHW Status | Read | ||||
| Fresh Water Station Circulation Pump | % | Read | |||
| Fresh Water Station Circulation Pump Status | Read | ||||
| Fresh Water Station Return Valve | % | Read | |||
| Fresh Water Station Return Valve Status | Read | ||||
| Fresh Water Station Tank Return Temperature | °C | Read | |||
| Fresh Water Station Disinfection Pump | % | Read | |||
| Fresh Water Station Disinfection Pump Status | Read | ||||
| Fresh Water Station Valve 1 | % | Read | |||
| Fresh Water Station Total DHW Flow | l/min | Read | |||
| Fresh Water Station DHW Temperature 2 | °C | Read | |||
| Fresh Water Station DHW Flow 2 | l/min | Read | |||
| Fresh Water Station Buffer Flow Temperature 2 | °C | Read | |||
| Fresh Water Station Cold Water Temperature 2 | °C | Read | |||
| Fresh Water Station Valve 2 | % | Read | |||
| Fresh Water Station Primary Pump 2 | % | Read | |||
| Fresh Water Station Primary Pump Status 2 | Read | ||||
| Fresh Water Station DHW Temperature 3 | °C | Read | |||
| Fresh Water Station DHW Flow 3 | l/min | Read | |||
| Fresh Water Station Buffer Flow Temperature 3 | °C | Read | |||
| Fresh Water Station Cold Water Temperature 3 | °C | Read | |||
| Fresh Water Station Valve 3 | % | Read | |||
| Fresh Water Station Primary Pump 3 | % | Read | |||
| Fresh Water Station Primary Pump Status 3 | Read | ||||
| Fresh Water Station DHW Temperature 4 | °C | Read | |||
| Fresh Water Station DHW Flow 4 | l/min | Read | |||
| Fresh Water Station Buffer Flow Temperature 4 | °C | Read | |||
| Fresh Water Station Cold Water Temperature 4 | °C | Read | |||
| Fresh Water Station Valve 4 | % | Read | |||
| Fresh Water Station Primary Pump 4 | % | Read | |||
| Fresh Water Station Primary Pump Status 4 | Read | ||||
| Fresh Water Station HMI Status | Read | ||||
| Fresh Water Station Configuration | Read | ||||
| Alternative Heat Generator Operating Hours | h | Read | |||
| Alternative Heat Generator Starts | Read | ||||
| Alternative Heat Generator Hours to Service | h | Read | |||
| Alternative Heat Generator HMI Status | Read | ||||
| Alternative Heat Generator Status Bits | Read | ||||
| Alternative Heat Generator System Return Temperature FAR | °C | Read | |||
| Alternative Heat Generator Buffer Middle Temperature FPM | °C | Read | |||
| Alternative Heat Generator Buffer Top Temperature FPO | °C | Read | |||
| Alternative Heat Generator Buffer Bottom Temperature FPU | °C | Read | |||
| Alternative Heat Generator Flue Gas Temperature | °C | Read | |||
| Alternative Heat Generator Return Temperature FWR | °C | Read | |||
| Alternative Heat Generator Flow Temperature FWV | °C | Read | |||
| Alternative Heat Generator Actuator Position | % | Read | |||
| Alternative Heat Generator SWE Bypass Position | Read | ||||
| CHP Flow Temperature | °C | Read | |||
| CHP Return Temperature | °C | Read | |||
| CHP Flue Gas Temperature | °C | Read | |||
| CHP Engine Temperature | °C | Read | |||
| CHP Generator Power | kW | Read | |||
| CHP Generator Power Setpoint | kW | Read | |||
| CHP Operating Hours | h | Read | |||
| CHP Starts | Read | ||||
| CHP Hours to Service | h | Read | |||
| CHP Output Setpoint | kW | Read | |||
| CHP HMI Status | Read | ||||
| CHP Status Bits | Read | ||||
| Heat Pump 0 Operating Mode | Read | ||||
| Heat Pump 1 Operating Mode | Read | ||||
| Heat Pump 2 Operating Mode | Read | ||||
| Heat Pump 3 Operating Mode | Read | ||||
| Heat Pump 4 Operating Mode | Read | ||||
| Heat Pump 5 Operating Mode | Read | ||||
| Heat Pump 6 Operating Mode | Read | ||||
| Heat Pump 7 Operating Mode | Read | ||||
| Heat Pump Cascade Heat Output | kW | Read | |||
| Heat Pump 1 Heat Output | kW | Read | |||
| Heat Pump 2 Heat Output | kW | Read | |||
| Heat Pump 3 Heat Output | kW | Read | |||
| Heat Pump 4 Heat Output | kW | Read | |||
| Heat Pump 5 Heat Output | kW | Read | |||
| Heat Pump 6 Heat Output | kW | Read | |||
| Heat Pump 7 Heat Output | kW | Read | |||
| Heat Pump Count in Cascade | Read | ||||
| Heat Pump Control Temperature | °C | Read | |||
| Heat Pump Cascade Electrical Input | kW | Read | |||
| Heat Pump 1 Electrical Input | kW | Read | |||
| Heat Pump 2 Electrical Input | kW | Read | |||
| Heat Pump 3 Electrical Input | kW | Read | |||
| Heat Pump 4 Electrical Input | kW | Read | |||
| Heat Pump 5 Electrical Input | kW | Read | |||
| Heat Pump 6 Electrical Input | kW | Read | |||
| Heat Pump 7 Electrical Input | kW | Read | |||
| Heat Pump Buffer System Return Temperature | °C | Read | |||
| Heat Pump Buffer Middle Temperature | °C | Read | |||
| Heat Pump Buffer Top Temperature | °C | Read | |||
| Heat Pump Buffer Bottom Temperature | °C | Read | |||
| Heat Pump FWR Return Temperature | °C | Read | |||
| Heat Pump FWV Flow Temperature | °C | Read | |||
| Heat Pump Flow Temperature | °C | Read | |||
| Heat Pump Return Temperature | °C | Read | |||
| Heat Pump HMI Status | Read | ||||
| Heat Pump 0 Heat Output | kW | Read | |||
| Heat Pump 0 Electrical Input | kW | Read | |||
| Heat Pump Smart Grid Mode | Read | ||||
| Heat Pump Heat Demand Setpoint | °C | Read | |||
| Heat Pump Status Bits | Read | ||||
| Heat Pump Ambient Temperature | °C | Read | |||
| Heat Pump Silent Mode | Read | ||||
| Heat Pump Temperature Setpoint | °C | Read | |||
| Heat Pump Demand Bits | Read | ||||
| Heat Pump Bypass Valve | Read | ||||
| Heat Pump Changeover Valve Source | Read | ||||
| Heat Pump Changeover Valve Status | Read | ||||
| Heat Pump Cooling Setpoint Actual | °C | Read | |||
| Heat Pump Cooling Demand Source | Read | ||||
| Heat Pump Cooling Buffer Top Temperature | °C | Read | |||
| Heat Pump Cooling Buffer Middle Temperature | °C | Read | |||
| Heat Pump Cooling Buffer Bottom Temperature | °C | Read | |||
| Heat Pump 0 Efficiency | Read | ||||
| Heat Pump 1 Efficiency | Read | ||||
| Heat Pump 2 Efficiency | Read | ||||
| Heat Pump 3 Efficiency | Read | ||||
| Heat Pump 4 Efficiency | Read | ||||
| Heat Pump 5 Efficiency | Read | ||||
| Heat Pump 6 Efficiency | Read | ||||
| Heat Pump 7 Efficiency | Read | ||||
| Solar Collector Temperature | °C | Read | |||
| Solar Tank 1 Bottom Temperature | °C | Read | |||
| Solar Pump | % | Read | |||
| Solar Pump Status | Read | ||||
| Solar Heat Exchanger Temperature | °C | Read | |||
| Solar Heat Exchanger Pump | % | Read | |||
| Solar Heat Exchanger Pump Status | Read | ||||
| Solar Tank 3 Top Temperature | °C | Read | |||
| Solar Transfer Pump | % | Read | |||
| Solar Transfer Pump Status | Read | ||||
| Solar Disinfection Pump Status | Read | ||||
| Solar Heat Meter Flow Temperature | °C | Read | |||
| Solar Heat Meter Return Temperature | °C | Read | |||
| Solar Pulse Counter | Read | ||||
| Solar Yield per Month | kWh | Read | |||
| Solar Yield per Year | kWh | Read | |||
| Solar Yield Last Hour | kWh | Read | |||
| Solar Yield per Day | kWh | Read | |||
| Solar Yield Since Installation | kWh | Read | |||
| Solar HMI Status | Read | ||||
| Solar Configuration | Read | ||||
| Solar Status Bits | Read | ||||
| Desalination Bypass Mode | Read | ||||
| Desalination Bypass Temperature | °C | Read | |||
| Desalination Bypass Flow Rate | l/min | Read | |||
| Desalination Bypass Heating Water Conductivity | µS/cm | Read | |||
| Desalination Bypass Cartridge Conductivity | µS/cm | Read | |||
| Desalination Bypass Cartridge Capacity Left | % | Read | |||
| SDC Desired Mode Low Priority | Read | ||||
| SDC Desired Flow Temperature Low Priority | °C | Read | |||
| SDC Desired Mode High Priority | Read | ||||
| SDC Desired Flow Temperature High Priority | °C | Read | |||
| System Connected Slaves | Read | ||||
| System Active Functions 1 | Read | ||||
| System Active Functions 2 | Read | ||||
| I2C Bus Global Error State | Read | ||||
| I2C Slot 1 Module Detected | Read | ||||
| I2C Slot 1 Error | Read | ||||
| I2C Slot 2 Module Detected | Read | ||||
| I2C Slot 2 Error | Read | ||||
| I2C Slot 3 Module Detected | Read | ||||
| I2C Slot 3 Error | Read | ||||
| I2C Slot 4 Module Detected | Read | ||||
| I2C Slot 4 Error | Read | ||||
| I2C Slot A Module Detected | Read | ||||
| I2C Slot A Error | Read | ||||
| I2C Bus Status Bits | Read | ||||
| FM-SI Input Fault Bits | Read | ||||
| System Pending Fault Count | Read | ||||
| System Fault Register 5 | Read | ||||
| System Fault Register 6 | Read | ||||
| System Fault Register 7 | Read | ||||
| System Fault Register 8 | Read | ||||
| System Fault Register 9 | Read | ||||
| System Fault Register 10 | Read | ||||
| System Fault Register 1 | Read | ||||
| System Fault Register 2 | Read | ||||
| System Fault Register 3 | Read | ||||
| System Fault Register 4 | Read | ||||
| System Fault Register 1 Info MSB | Read | ||||
| System Fault Register 1 Info LSB | Read | ||||
| System Fault Register 2 Info MSB | Read | ||||
| System Fault Register 2 Info LSB | Read | ||||
| System Fault Register 3 Info MSB | Read | ||||
| System Fault Register 3 Info LSB | Read | ||||
| System Fault Register 4 Info MSB | Read | ||||
| System Fault Register 4 Info LSB | Read | ||||
| System Heartbeat In | Read and write | ||||
| System Heartbeat Out | Read | ||||
| Strategy Flow Temperature Demand | °C | Read and write | |||
| Strategy Output Demand | % | Read and write | |||
| Strategy Heat Generator Mode | Read and write | ||||
| Strategy Control Bits | Read and write | ||||
| Cascade Buffer Charging Start Offset | K | Read and write | |||
| Cascade Buffer Charging Stop Offset | K | Read and write | |||
| Cascade Buffer Charging Setpoint Offset | K | Read and write | |||
| Cascade Fast Buffer Charging Setpoint | °C | Read and write | |||
| Cascade Fast Buffer Charging Hysteresis | K | Read and write | |||
| Cascade Allowed Min Modulation Buffer Charging | % | Read and write | |||
| Cascade Fast Buffer Charging Runtime | h | Read and write | |||
| Cascade Fast Buffer Charging Bits | Read and write | ||||
| DHW 1 Manual Mode | Read and write | ||||
| DHW 1 Auto/Manual Mode | Read and write | ||||
| DHW 1 Thermal Disinfection Temperature | °C | Read and write | |||
| DHW 1 Auto Heating Setpoint | °C | Read and write | |||
| DHW 1 Auto Setback Setpoint | °C | Read and write | |||
| DHW 1 Manual Heating Setpoint | °C | Read and write | |||
| DHW 1 Manual Setback Setpoint | °C | Read and write | |||
| DHW 1 Holiday Setpoint | °C | Read and write | |||
| DHW 1 Circulation Pump Auto/Manual | Read and write | ||||
| DHW 1 Circulation Pump Manual Mode | Read and write | ||||
| DHW 1 Thermal Disinfection Frequency | Read and write | ||||
| DHW 1 Thermal Disinfection Start Hour | h | Read and write | |||
| DHW 2 Manual Mode | Read and write | ||||
| DHW 2 Auto/Manual Mode | Read and write | ||||
| DHW 2 Thermal Disinfection Temperature | °C | Read and write | |||
| DHW 2 Auto Heating Setpoint | °C | Read and write | |||
| DHW 2 Auto Setback Setpoint | °C | Read and write | |||
| DHW 2 Manual Heating Setpoint | °C | Read and write | |||
| DHW 2 Manual Setback Setpoint | °C | Read and write | |||
| DHW 2 Holiday Setpoint | °C | Read and write | |||
| DHW 2 Circulation Pump Auto/Manual | Read and write | ||||
| DHW 2 Circulation Pump Manual Mode | Read and write | ||||
| DHW 2 Thermal Disinfection Frequency | Read and write | ||||
| DHW 2 Thermal Disinfection Start Hour | h | Read and write | |||
| Heating Circuit 00 Auto/Manual Mode | Read and write | ||||
| Heating Circuit 00 Manual Mode | Read and write | ||||
| Heating Circuit 00 Auto Heating Setpoint | °C | Read and write | |||
| Heating Circuit 00 Auto Setback Setpoint | °C | Read and write | |||
| Heating Circuit 00 Manual Heating Setpoint | °C | Read and write | |||
| Heating Circuit 00 Manual Setback Setpoint | °C | Read and write | |||
| Heating Circuit 00 Holiday Setpoint | °C | Read and write | |||
| Heating Circuit 00 Offset | K | Read and write | |||
| Heating Circuit 01 Auto/Manual Mode | Read and write | ||||
| Heating Circuit 01 Manual Mode | Read and write | ||||
| Heating Circuit 01 Auto Heating Setpoint | °C | Read and write | |||
| Heating Circuit 01 Auto Setback Setpoint | °C | Read and write | |||
| Heating Circuit 01 Manual Heating Setpoint | °C | Read and write | |||
| Heating Circuit 01 Manual Setback Setpoint | °C | Read and write | |||
| Heating Circuit 01 Holiday Setpoint | °C | Read and write | |||
| Heating Circuit 01 Offset | K | Read and write | |||
| Heating Circuit 02 Auto/Manual Mode | Read and write | ||||
| Heating Circuit 02 Manual Mode | Read and write | ||||
| Heating Circuit 02 Auto Heating Setpoint | °C | Read and write | |||
| Heating Circuit 02 Auto Setback Setpoint | °C | Read and write | |||
| Heating Circuit 02 Manual Heating Setpoint | °C | Read and write | |||
| Heating Circuit 02 Manual Setback Setpoint | °C | Read and write | |||
| Heating Circuit 02 Holiday Setpoint | °C | Read and write | |||
| Heating Circuit 02 Offset | K | Read and write | |||
| Heating Circuit 03 Auto/Manual Mode | Read and write | ||||
| Heating Circuit 03 Manual Mode | Read and write | ||||
| Heating Circuit 03 Auto Heating Setpoint | °C | Read and write | |||
| Heating Circuit 03 Auto Setback Setpoint | °C | Read and write | |||
| Heating Circuit 03 Manual Heating Setpoint | °C | Read and write | |||
| Heating Circuit 03 Manual Setback Setpoint | °C | Read and write | |||
| Heating Circuit 03 Holiday Setpoint | °C | Read and write | |||
| Heating Circuit 03 Offset | K | Read and write | |||
| Heating Circuit 04 Auto/Manual Mode | Read and write | ||||
| Heating Circuit 04 Manual Mode | Read and write | ||||
| Heating Circuit 04 Auto Heating Setpoint | °C | Read and write | |||
| Heating Circuit 04 Auto Setback Setpoint | °C | Read and write | |||
| Heating Circuit 04 Manual Heating Setpoint | °C | Read and write | |||
| Heating Circuit 04 Manual Setback Setpoint | °C | Read and write | |||
| Heating Circuit 04 Holiday Setpoint | °C | Read and write | |||
| Heating Circuit 04 Offset | K | Read and write | |||
| Heating Circuit 05 Auto/Manual Mode | Read and write | ||||
| Heating Circuit 05 Manual Mode | Read and write | ||||
| Heating Circuit 05 Auto Heating Setpoint | °C | Read and write | |||
| Heating Circuit 05 Auto Setback Setpoint | °C | Read and write | |||
| Heating Circuit 05 Manual Heating Setpoint | °C | Read and write | |||
| Heating Circuit 05 Manual Setback Setpoint | °C | Read and write | |||
| Heating Circuit 05 Holiday Setpoint | °C | Read and write | |||
| Heating Circuit 05 Offset | K | Read and write | |||
| Heating Circuit 06 Auto/Manual Mode | Read and write | ||||
| Heating Circuit 06 Manual Mode | Read and write | ||||
| Heating Circuit 06 Auto Heating Setpoint | °C | Read and write | |||
| Heating Circuit 06 Auto Setback Setpoint | °C | Read and write | |||
| Heating Circuit 06 Manual Heating Setpoint | °C | Read and write | |||
| Heating Circuit 06 Manual Setback Setpoint | °C | Read and write | |||
| Heating Circuit 06 Holiday Setpoint | °C | Read and write | |||
| Heating Circuit 06 Offset | K | Read and write | |||
| Heating Circuit 07 Auto/Manual Mode | Read and write | ||||
| Heating Circuit 07 Manual Mode | Read and write | ||||
| Heating Circuit 07 Auto Heating Setpoint | °C | Read and write | |||
| Heating Circuit 07 Auto Setback Setpoint | °C | Read and write | |||
| Heating Circuit 07 Manual Heating Setpoint | °C | Read and write | |||
| Heating Circuit 07 Manual Setback Setpoint | °C | Read and write | |||
| Heating Circuit 07 Holiday Setpoint | °C | Read and write | |||
| Heating Circuit 07 Offset | K | Read and write | |||
| Heating Circuit 08 Auto/Manual Mode | Read and write | ||||
| Heating Circuit 08 Manual Mode | Read and write | ||||
| Heating Circuit 08 Auto Heating Setpoint | °C | Read and write | |||
| Heating Circuit 08 Auto Setback Setpoint | °C | Read and write | |||
| Heating Circuit 08 Manual Heating Setpoint | °C | Read and write | |||
| Heating Circuit 08 Manual Setback Setpoint | °C | Read and write | |||
| Heating Circuit 08 Holiday Setpoint | °C | Read and write | |||
| Heating Circuit 08 Offset | K | Read and write | |||
| Alternative Heat Generator Auto Heating Mode Temperature | °C | Read and write | |||
| Alternative Heat Generator Auto Setback Mode Temperature | °C | Read and write | |||
| Alternative Heat Generator Manual Heating Mode Temperature | °C | Read and write | |||
| Alternative Heat Generator Manual Setback Mode Temperature | °C | Read and write | |||
| Alternative Heat Generator Holiday Mode Temperature | °C | Read and write | |||
| Alternative Heat Generator Auto/Manual Mode | Read and write | ||||
| Alternative Heat Generator Manual Mode | Read and write | ||||
| Alternative Heat Generator Return Temperature Setpoint | °C | Read and write | |||
| Heat Pump Demand Source | Read and write | ||||
| Heat Pump Changeover Valve | Read and write | ||||
| Heat Pump Cooling Mode | Read and write | ||||
| Heat Pump Cooling Setpoint | °C | Read and write | |||
| MDC Outdoor Temperature | °C | Read and write | |||
| MDC Damped Outdoor Temperature | °C | Read | |||
| MDC Minimum Outdoor Temperature | °C | Read | |||
| MDC System Flow Temperature | °C | Read | |||
| Boiler Control Type | Read | ||||
| Fresh Water Station Daily Heat-Up Temperature | °C | Read | |||
| Fresh Water Station One-Time Charge Temperature | °C | Read | |||
| Fresh Water Station Max DHW Temperature | °C | Read | |||
| Fresh Water Station Required DHW Temperature | °C | Read | |||
| Fresh Water Station Reduced DHW Temperature | °C | Read | |||
| Fresh Water Station Size | Read | ||||
| Fresh Water Station Fault Display Enabled | Read | ||||
| Fresh Water Station Tank Temperature Increase | K | Read | |||
| Fresh Water Station Function Bits | Read | ||||
| Fresh Water Station Min Tank Temperature Increase | K | Read | |||
| Fresh Water Station Circulation Pump Frequency | Read | ||||
| Fresh Water Station Return-Sensitive Stratification Differential | K | Read | |||
| Fresh Water Station Thermal Disinfection Temperature | °C | Read | |||
| Fresh Water Station Max Preheat Temperature | °C | Read |
Loading registers…
Send your device list
If a device is not in the library yet, we build the template for free as soon as we have the register data.
Use cases
- Put system flow temperature, cascade output and the flow and return temperature of each boiler on one dashboard for the boiler house.
- Get an email or webhook alert when a boiler, a heating circuit or the system reports HMI status fault or critical.
- Track burner starts, operating time and flue gas temperature per boiler over 365 days to plan maintenance.
- Compare flow temperature setpoint and actual flow temperature per heating circuit to see which greenhouse section falls short.
- Write the flow temperature demand from an automation on a time schedule or an energy price trigger.
- Keep a history of hot water temperatures and thermal disinfection status and share it as a PDF report.
Installation
Connect the LAN1 socket on the BCT 531 module of the controller to the same network as the ModbusCloud Gateway.
On the controller, open the service menu with a long press on the fault overview symbol, go to Konnektivität and set Local Area Network to Modbus TCP/IP.
Set Kommunikation Modbus to Ohne Heart Beat, turn on Erweiterte Monitordaten der Anlage bereitstellen, give the controller a fixed IP address outside 172.31.42.x and save.
In ModbusCloud, add a Modbus device with Modbus TCP, the IP address of the controller, port 502 and unit ID 255, then import this template.
Check that System Outdoor Temperature and System Flow Temperature show plausible values. Boilers, circuits and modules that are not installed read 0.
Things to watch for
The controller does not answer or every value reads 0. What should I check?
Local Area Network must be set to Modbus TCP/IP, and Kommunikation Modbus must not be Nein, because that turns Modbus off. Erweiterte Monitordaten der Anlage bereitstellen has to be on. Use port 502 and unit ID 255 unless the ID was changed in the menu. Boilers, heating circuits and modules that are not installed or not configured always read 0.
How do I send a heat demand to the boilers from ModbusCloud?
Writing is off per gateway until you request it in the portal. On the controller, enable Wärmeanforderung über Modbus. For a temperature demand write 1 to Strategy Heat Generator Mode, the flow temperature to Strategy Flow Temperature Demand and 7 to Strategy Control Bits. For an output demand write the percentage to Strategy Output Demand and 9 to Strategy Control Bits, with the internal heat demand switched off.
The controller reports that the building management connection is lost. Why?
With Kommunikation Modbus set to Mit Heart Beat, the controller expects a new value in System Heartbeat In before its timeout of 120 to 600 seconds, 180 by default. ModbusCloud does not write this counter by itself, so for monitoring choose Ohne Heart Beat.
How do I read a second Logamatic 5000 that runs as slave?
A slave is read through the master. For addresses below 8000, add 500 times the rotary switch position of the slave to the master address: the flow temperature of heating circuit 01 at input register 102 becomes 602 for slave 1. Boiler data from address 8000 up exist only on the master. Make your own template in ModbusCloud with the shifted addresses.
How do I read the fault registers and display codes?
System Fault Register 1 to 10 hold the message keys of pending messages, and a key stays until the message is resolved on the controller. Buderus supplies a message key list to translate them. Boiler Fault Code holds the numeric fault code and Boiler Display Code shows the two characters from the boiler display, for example 2P or -H.
Want to see how it works?
