Siemens SITRANS FM MAG 6000

Name: Siemens SITRANS FM MAG 6000
Brand: Siemens
SKU: 110c55fe-8d08-49ec-b415-f021d8ab33b6

Electromagnetic flow transmitter for water and other conductive liquids, with flow, totalizers and error status.

The Siemens SITRANS FM MAG 6000 is an electromagnetic flow transmitter that measures the flow and total volume of conductive liquids, such as irrigation water and drain water in greenhouses. This Modbus RTU template reads volume flow, both totalizers, error status and identity, and lets you reset totalizers, run batches and change flow, output and display settings from ModbusCloud.

Protocol: Modbus RTU
Connection: RS485, 19200 baud
Registers: 291, read and write

Brand: Siemens
Key readings: Volume flow · Totalizer 1 · Totalizer 2 · System status · Pending errors · Batch status · Operating time · Transmitter and sensor identity
Available commands: Totalizer reset and hold · Batch start and pause · Q max and low flow cut off · Output and batch settings · Flow and totalizer units · Modbus address and baud rate
Compatible models: SITRANS FM MAG 6000 · SITRANS FM MAG 6000 19" · SITRANS FM MAG 6000 I · SITRANS FM MAG 6000 SV
Last updated: 7 October 2026

Registers (291)

291 read, 75 write

Name	Unit	Access
Volume Flow		Read
Totalizer 1		Read
Totalizer 2		Read
Totalizer 1 Float		Read
Totalizer 2 Float		Read
System Status		Read
Error Pending 1		Read
Error Pending 2		Read
Error Pending 3		Read
Error Pending 4		Read
Error Pending 5		Read
Error Pending 6		Read
Error Pending 7		Read
Error Pending 8		Read
Error Pending 9		Read
Batch Status		Read
Zero Adjust Progress		Read
Run Indicator		Read
Operating Time	s	Read
Reset Totalizer 1		Read and write
Hold Totalizer 1		Read and write
Reset Totalizer 2		Read and write
Hold Totalizer 2		Read and write
Start Batch		Read and write
Pause Batch		Read and write
Start Auto Zero Adjust		Read and write
Restart Modbus Communication		Read and write
Flow Direction		Read and write
Q Max	m³/s	Read and write
Q Max 2 Night	m³/s	Read and write
Low Flow Cut Off		Read and write
Empty Pipe Detection		Read and write
Error Level		Read and write
Zero Adjust Mode		Read and write
Manual Zero Adjust	m³/s	Read and write
Mains Frequency		Read and write
Totalizer 1 Direction		Read and write
Totalizer 2 Direction		Read and write
Current Output 1 Selection		Read and write
Current Output 1 Direction		Read and write
Current Output 1 Range		Read and write
Current Output 1 Time Constant		Read and write
Digital Output 1 Function		Read and write
Pulse 1 Direction		Read and write
Pulse 1 Width		Read and write
Frequency 1 Direction		Read and write
Frequency 1 Fmax		Read and write
Frequency 1 Time Constant		Read and write
Limit Digital Mode		Read and write
Limit Digital Setpoint Min		Read and write
Limit Digital Setpoint Max		Read and write
Limit Digital Hysteresis		Read and write
Relay Output 1 Function		Read and write
Limit Relay Mode		Read and write
Limit Relay Setpoint Min		Read and write
Limit Relay Setpoint Max		Read and write
Limit Relay Hysteresis		Read and write
Output Error Number		Read and write
Batch Quantity	m³	Read and write
Batch Compensation	m³	Read and write
Batch Time Error		Read and write
Batch Time	s	Read and write
Batch Overrun		Read and write
Batch Overrun Error	m³	Read and write
Batch Counter Direction		Read and write
Batch Time Constant		Read and write
Batch Cycle Counter		Read
Cleaning Cycle Time	s	Read and write
Volume Per Pulse	m³	Read and write
Pulse Polarity		Read and write
Pulse Timeout	s	Read and write
External Input Function		Read and write
External Input Totalizer Reset		Read and write
Force Output		Read and write
Sensor Size	m	Read and write
Calibration Factor		Read and write
Correction Factor		Read and write
Excitation Frequency		Read and write
Volume Flow Unit		Read and write
Volume Flow Decimals		Read and write
Totalizer 1 Unit		Read and write
Totalizer 1 Decimals		Read and write
Totalizer 2 Unit		Read and write
Totalizer 2 Decimals		Read and write
Display Language		Read and write
Display Line 1		Read and write
Display Line 2		Read and write
Display Line 3		Read and write
Device Address		Read and write
Baud Rate		Read and write
Parity Framing		Read and write
Response Timeout	ms	Read and write
Response Delay	ms	Read and write
Interframe Space Setting		Read and write
Interframe Space	ms	Read
Baud Rate Value		Read
Parity Errors		Read
Framing Errors		Read
CRC Errors		Read
OK Messages		Read
Last Coil Error Address		Read
Last Coil Error Number		Read
Last Holding Register Error Address		Read
Last Holding Register Error Number		Read
Slave ID		Read
Product Code		Read
Capability Bits		Read
Flowmeter Revision		Read
Modbus Revision		Read
Manufacturer Name		Read
Product Name		Read
Modbus Module Name		Read
Tag		Read and write
Modbus Module SW Version		Read
Modbus Module HW Version		Read
Converter Type		Read
Converter Code Number		Read
Converter Serial Number		Read
Converter SW Version		Read
Sensor Type		Read
Sensor Code Number		Read
Sensor Serial Number		Read
Sensor Size Text		Read
Pending List 1 Error Number		Read
Pending List 1 Category And Age		Read
Pending List 2 Error Number		Read
Pending List 2 Category And Age		Read
Pending List 3 Error Number		Read
Pending List 3 Category And Age		Read
Pending List 4 Error Number		Read
Pending List 4 Category And Age		Read
Pending List 5 Error Number		Read
Pending List 5 Category And Age		Read
Pending List 6 Error Number		Read
Pending List 6 Category And Age		Read
Pending List 7 Error Number		Read
Pending List 7 Category And Age		Read
Pending List 8 Error Number		Read
Pending List 8 Category And Age		Read
Pending List 9 Error Number		Read
Pending List 9 Category And Age		Read
Error Log 1 Error Number		Read
Error Log 1 Category And Age		Read
Error Log 2 Error Number		Read
Error Log 2 Category And Age		Read
Error Log 3 Error Number		Read
Error Log 3 Category And Age		Read
Error Log 4 Error Number		Read
Error Log 4 Category And Age		Read
Error Log 5 Error Number		Read
Error Log 5 Category And Age		Read
Error Log 6 Error Number		Read
Error Log 6 Category And Age		Read
Error Log 7 Error Number		Read
Error Log 7 Category And Age		Read
Error Log 8 Error Number		Read
Error Log 8 Category And Age		Read
Error Log 9 Error Number		Read
Error Log 9 Category And Age		Read
Flow Direction Lower Limit		Read
Flow Direction Upper Limit		Read
Q Max Lower Limit	m³/s	Read
Q Max Upper Limit	m³/s	Read
Q Max 2 Night Lower Limit	m³/s	Read
Q Max 2 Night Upper Limit	m³/s	Read
Low Flow Cut Off Lower Limit		Read
Low Flow Cut Off Upper Limit		Read
Empty Pipe Detection Lower Limit		Read
Empty Pipe Detection Upper Limit		Read
Error Level Lower Limit		Read
Error Level Upper Limit		Read
Zero Adjust Mode Lower Limit		Read
Zero Adjust Mode Upper Limit		Read
Manual Zero Adjust Lower Limit	m³/s	Read
Manual Zero Adjust Upper Limit	m³/s	Read
Mains Frequency Lower Limit		Read
Mains Frequency Upper Limit		Read
Totalizer 1 Direction Lower Limit		Read
Totalizer 1 Direction Upper Limit		Read
Totalizer 2 Direction Lower Limit		Read
Totalizer 2 Direction Upper Limit		Read
Current Output 1 Selection Lower Limit		Read
Current Output 1 Selection Upper Limit		Read
Current Output 1 Direction Lower Limit		Read
Current Output 1 Direction Upper Limit		Read
Current Output 1 Range Lower Limit		Read
Current Output 1 Range Upper Limit		Read
Current Output 1 Time Constant Lower Limit		Read
Current Output 1 Time Constant Upper Limit		Read
Digital Output 1 Function Lower Limit		Read
Digital Output 1 Function Upper Limit		Read
Pulse 1 Direction Lower Limit		Read
Pulse 1 Direction Upper Limit		Read
Pulse 1 Width Lower Limit		Read
Pulse 1 Width Upper Limit		Read
Frequency 1 Direction Lower Limit		Read
Frequency 1 Direction Upper Limit		Read
Frequency 1 Fmax Lower Limit		Read
Frequency 1 Fmax Upper Limit		Read
Frequency 1 Time Constant Lower Limit		Read
Frequency 1 Time Constant Upper Limit		Read
Limit Digital Mode Lower Limit		Read
Limit Digital Mode Upper Limit		Read
Limit Digital Setpoint Min Lower Limit		Read
Limit Digital Setpoint Min Upper Limit		Read
Limit Digital Setpoint Max Lower Limit		Read
Limit Digital Setpoint Max Upper Limit		Read
Limit Digital Hysteresis Lower Limit		Read
Limit Digital Hysteresis Upper Limit		Read
Relay Output 1 Function Lower Limit		Read
Relay Output 1 Function Upper Limit		Read
Limit Relay Mode Lower Limit		Read
Limit Relay Mode Upper Limit		Read
Limit Relay Setpoint Min Lower Limit		Read
Limit Relay Setpoint Min Upper Limit		Read
Limit Relay Setpoint Max Lower Limit		Read
Limit Relay Setpoint Max Upper Limit		Read
Limit Relay Hysteresis Lower Limit		Read
Limit Relay Hysteresis Upper Limit		Read
Output Error Number Lower Limit		Read
Output Error Number Upper Limit		Read
Batch Quantity Lower Limit	m³	Read
Batch Quantity Upper Limit	m³	Read
Batch Compensation Lower Limit	m³	Read
Batch Compensation Upper Limit	m³	Read
Batch Time Error Lower Limit		Read
Batch Time Error Upper Limit		Read
Batch Time Lower Limit	s	Read
Batch Time Upper Limit	s	Read
Batch Overrun Lower Limit		Read
Batch Overrun Upper Limit		Read
Batch Overrun Error Lower Limit	m³	Read
Batch Overrun Error Upper Limit	m³	Read
Batch Counter Direction Lower Limit		Read
Batch Counter Direction Upper Limit		Read
Batch Time Constant Lower Limit		Read
Batch Time Constant Upper Limit		Read
Cleaning Cycle Time Lower Limit	s	Read
Cleaning Cycle Time Upper Limit	s	Read
Volume Per Pulse Lower Limit	m³	Read
Volume Per Pulse Upper Limit	m³	Read
Pulse Polarity Lower Limit		Read
Pulse Polarity Upper Limit		Read
Pulse Timeout Lower Limit	s	Read
Pulse Timeout Upper Limit	s	Read
External Input Function Lower Limit		Read
External Input Function Upper Limit		Read
External Input Totalizer Reset Lower Limit		Read
External Input Totalizer Reset Upper Limit		Read
Force Output Lower Limit		Read
Force Output Upper Limit		Read
Sensor Size Lower Limit	m	Read
Sensor Size Upper Limit	m	Read
Calibration Factor Lower Limit		Read
Calibration Factor Upper Limit		Read
Correction Factor Lower Limit		Read
Correction Factor Upper Limit		Read
Excitation Frequency Lower Limit		Read
Excitation Frequency Upper Limit		Read
Volume Flow Unit Lower Limit		Read
Volume Flow Unit Upper Limit		Read
Volume Flow Decimals Lower Limit		Read
Volume Flow Decimals Upper Limit		Read
Totalizer 1 Unit Lower Limit		Read
Totalizer 1 Unit Upper Limit		Read
Totalizer 1 Decimals Lower Limit		Read
Totalizer 1 Decimals Upper Limit		Read
Totalizer 2 Unit Lower Limit		Read
Totalizer 2 Unit Upper Limit		Read
Totalizer 2 Decimals Lower Limit		Read
Totalizer 2 Decimals Upper Limit		Read
Display Language Lower Limit		Read
Display Language Upper Limit		Read
Display Line 1 Lower Limit		Read
Display Line 1 Upper Limit		Read
Display Line 2 Lower Limit		Read
Display Line 2 Upper Limit		Read
Display Line 3 Lower Limit		Read
Display Line 3 Upper Limit		Read
Device Address Lower Limit		Read
Device Address Upper Limit		Read
Baud Rate Lower Limit		Read
Baud Rate Upper Limit		Read
Parity Framing Lower Limit		Read
Parity Framing Upper Limit		Read
Response Timeout Lower Limit	ms	Read
Response Timeout Upper Limit	ms	Read
Response Delay Lower Limit	ms	Read
Response Delay Upper Limit	ms	Read
Interframe Space Setting Lower Limit		Read
Interframe Space Setting Upper Limit		Read

Loading registers…

Send your device list

If a device is not in the library yet, we build the template for free as soon as we have the register data.

Use cases

Show flow and both totalizers of each irrigation and drain water line on one dashboard.
Get an alert when the flow rises above its normal maximum, a sign of a leak or a burst pipe.
Compare daily water use per line from the totalizer history, which ModbusCloud keeps for 365 days.
Receive an email or webhook alert when the transmitter reports a pending error.
Reset or hold a totalizer and start or pause a batch remotely, without walking to the meter.
Check Q max, units and output settings of every meter from the office before you change them.

Installation

Switch off the transmitter and fit the Modbus RTU add-on module FDK-085U0234. After power-up the display menu has a MODBUS RTU entry.
Connect terminal 92 (Data+) and 93 (Data-) to the RS485 port of the ModbusCloud Gateway and the shield to PE. On the last device on the bus, link 91 to 92 and 93 to 94.
In the MODBUS RTU menu, check address, baud rate and parity (factory setting 1, 19200, even, 1 stop bit). Give each meter on the bus its own address.
In ModbusCloud, add a Modbus device (RTU) with the same address and serial settings and import this template.
Compare Volume Flow with the display and read Volume Flow Unit and Totalizer 1 Unit, so you can set the matching units in ModbusCloud.

Things to watch for

The meter does not answer. What should I check?

Check the MODBUS RTU menu on the display: factory setting address 1, 19200 baud, even parity, 1 stop bit. A new baud rate or parity only takes effect after a power cycle or after writing Restart Modbus Communication. Then swap Data+ and Data-, terminate the last device by linking 91 to 92 and 93 to 94, and ground the shield at one end only.

Which unit do flow and the totalizers have?

The unit selected on the transmitter, which Modbus and the display share. The factory default is m³/s for flow and m³ for the totalizers, but it is often changed at commissioning, for example to m³/h. Read Volume Flow Unit and Totalizer 1 Unit and give the registers the same unit in ModbusCloud. Q max, batch quantity and volume per pulse are always in m³/s and m³.

Why do some registers give an error or an odd value?

Zero Adjust Mode and Manual Zero Adjust exist only on the MAG 6000 SV. The module answers at most 26 registers per read. A lower or upper limit shows the full range of its data type when the setting has no own limit. Last Holding Register Error Number tells you why the last request was refused.

Can I reset totalizers or change settings from ModbusCloud?

Yes, once writing is enabled for the gateway; you request that per gateway in the portal. Reset and hold work through the totalizer commands. Units, Q max and output settings also change the display and the current, pulse and relay outputs, so agree changes with whoever uses those signals. Read the lower and upper limit first; a value outside them is refused.

More Siemens templates

All Siemens templates Browse the library

Want to see how it works?

View demo Order your first gateway

Electrician working in an open distribution board
