Janitza UMG 509-PRO
Power quality analyser for voltage, current, power, energy and harmonics on four channels.
The Janitza UMG 509-PRO is a power quality analyser that measures voltage, current, power, energy and harmonics on four channels in main and sub-distributions. This Modbus RTU template reads all measured values, energy counters and mean, minimum and maximum values, and lets you adjust transformer and display settings from ModbusCloud.
- Protocol
- Modbus RTU
- Connection
- RS485, 19200 baud
- Registers
- 915, read and write
- Brand
- Janitza
- Key readings
- Voltage L-N and L-L · Current per phase · Real power · Reactive power · Power factor · THD voltage and current · Frequency · Energy per tariff
- Available commands
- Current transformer ratio · Voltage transformer ratio · Modbus address and baud rate · Display settings
- Compatible models
- UMG 509-PRO
- Last updated
Registers (915)
915 read, 168 write
| Name | Unit | Access | Address (Hidden until you enter your email) | Function (hidden) | Type (hidden) |
|---|---|---|---|---|---|
| Voltage L1-N | V | Read | |||
| Voltage L2-N | V | Read | |||
| Voltage L3-N | V | Read | |||
| Voltage L1-L2 | V | Read | |||
| Voltage L2-L3 | V | Read | |||
| Voltage L3-L1 | V | Read | |||
| Apparent Current, L1 | A | Read | |||
| Apparent Current, L2 | A | Read | |||
| Apparent Current, L3 | A | Read | |||
| Vector Sum; IN=I1+I2+I3 | A | Read | |||
| Real Power L1 | W | Read | |||
| Real Power L2 | W | Read | |||
| Real Power L3 | W | Read | |||
| Sum; Psum3=P1+P2+P3 | W | Read | |||
| Apparent Power L1 | VA | Read | |||
| Apparent Power L2 | VA | Read | |||
| Apparent Power L3 | VA | Read | |||
| Sum; Ssum3=S1+S2+S3 | VA | Read | |||
| Reactive Power (mains Frequ.) L1 | var | Read | |||
| Reactive Power (mains Frequ.) L2 | var | Read | |||
| Reactive Power (mains Frequ.) L3 | var | Read | |||
| Sum; Qsum3=Q1+Q2+Q3 | var | Read | |||
| Fund.power Factor, CosPhi; UL1 IL1 | Read | ||||
| Fund.power Factor, CosPhi; UL2 IL2 | Read | ||||
| Fund.power Factor, CosPhi; UL3 IL3 | Read | ||||
| Measured Frequency | Hz | Read | |||
| Rotation Field; 1=right, 0=none, -1=left | Read | ||||
| Real Energy L1 | Wh | Read | |||
| Real Energy L2 | Wh | Read | |||
| Real Energy L3 | Wh | Read | |||
| Real Energy L1..L3 | Wh | Read | |||
| Real Energy L1, Consumed | Wh | Read | |||
| Real Energy L2, Consumed | Wh | Read | |||
| Real Energy L3, Consumed | Wh | Read | |||
| Real Energy L1..L3, Consumed, Rate 1 | Wh | Read | |||
| Real Energy L1, Delivered | Wh | Read | |||
| Real Energy L2, Delivered | Wh | Read | |||
| Real Energy L3, Delivered | Wh | Read | |||
| Real Energy L1..L3, Delivered | Wh | Read | |||
| Apparent Energy L1 | VAh | Read | |||
| Apparent Energy L2 | VAh | Read | |||
| Apparent Energy L3 | VAh | Read | |||
| Apparent Energy L1..L3 | VAh | Read | |||
| Reactive Energy L1 | varh | Read | |||
| Reactive Energy L2 | varh | Read | |||
| Reactive Energy L3 | varh | Read | |||
| Reactive Energy L1..L3 | varh | Read | |||
| Reactive Energy L1, Inductive | varh | Read | |||
| Reactive Energy L2, Inductive | varh | Read | |||
| Reactive Energy L3, Inductive | varh | Read | |||
| Reactive Energy L1..L3, Ind. | varh | Read | |||
| Reactive Energy L1, Capacitive | varh | Read | |||
| Reactive Energy L2, Capacitive | varh | Read | |||
| Reactive Energy L3, Capacitive | varh | Read | |||
| Reactive Energy L1..L3, Cap. | varh | Read | |||
| Harmonic, THD,U L1-N | % | Read | |||
| Harmonic, THD,U L2-N | % | Read | |||
| Harmonic, THD,U L3-N | % | Read | |||
| Harmonic, THD,I L1 | % | Read | |||
| Harmonic, THD,I L2 | % | Read | |||
| Harmonic, THD,I L3 | % | Read | |||
| Voltage Phase L-N | ° | Read and write | |||
| Voltage Phase L-N L2 | ° | Read and write | |||
| Voltage Phase L-N L3 | ° | Read and write | |||
| Harmonic, THD,U L1-N (200 ms) | % | Read | |||
| Harmonic, THD,U L2-N (200 ms) | % | Read | |||
| Harmonic, THD,U L3-N (200 ms) | % | Read | |||
| Harmonic, THD,U L4-N (200 ms) | % | Read | |||
| Harmonic, THD,I L1 (200 ms) | % | Read | |||
| Harmonic, THD,I L2 (200 ms) | % | Read | |||
| Harmonic, THD,I L3 (200 ms) | % | Read | |||
| Harmonic, THD,I L4 (200 ms) | % | Read | |||
| K-Factor L1 | Read | ||||
| K-Factor L2 | Read | ||||
| K-Factor L3 | Read | ||||
| K-Factor L4 | Read | ||||
| Voltage L1-N (200 ms) | V | Read | |||
| Voltage L2-N (200 ms) | V | Read | |||
| Voltage L3-N (200 ms) | V | Read | |||
| Voltage L4-N (200 ms) | V | Read | |||
| Apparent Current, L1 (200 ms) | A | Read | |||
| Apparent Current, L2 (200 ms) | A | Read | |||
| Apparent Current, L3 (200 ms) | A | Read | |||
| Apparent Current, L4 (200 ms) | A | Read | |||
| Real Power L1 (200 ms) | W | Read | |||
| Real Power L2 (200 ms) | W | Read | |||
| Real Power L3 (200 ms) | W | Read | |||
| Real Power L4 (200 ms) | W | Read | |||
| Reactive Power (mains Frequ.) L1 (200 ms) | var | Read | |||
| Reactive Power (mains Frequ.) L2 (200 ms) | var | Read | |||
| Reactive Power (mains Frequ.) L3 (200 ms) | var | Read | |||
| Reactive Power (mains Frequ.) L4 (200 ms) | var | Read | |||
| Apparent Power L1 (200 ms) | VA | Read | |||
| Apparent Power L2 (200 ms) | VA | Read | |||
| Apparent Power L3 (200 ms) | VA | Read | |||
| Apparent Power L4 (200 ms) | VA | Read | |||
| Phase Conductor Voltage; L1-L2 (200 ms) | V | Read | |||
| Phase Conductor Voltage; L2-L3 (200 ms) | V | Read | |||
| Phase Conductor Voltage; L1-L3 (200 ms) | V | Read | |||
| Vector Sum; IN=I1+I2+I3 (200 ms) | A | Read | |||
| Vector Sum; I1+I2+I3+I4 (200 ms) | A | Read | |||
| Sum; Ssum3=S1+S2+S3 (200 ms) | VA | Read | |||
| Sum; Psum3=P1+P2+P3 (200 ms) | W | Read | |||
| Sum; Qsum3=Q1+Q2+Q3 (200 ms) | var | Read | |||
| PSUM3 / Sqrt(P SUM3+ Q SUM3) (200 ms) | Read | ||||
| S1+S2+S3+S4 (200 ms) | VA | Read | |||
| P1+P2+P3+P4 (200 ms) | W | Read | |||
| Q1+Q2+Q3+Q4 (200 ms) | var | Read | |||
| PSUM / Sqrt(P SUM+ Q SUM) (200 ms) | Read | ||||
| Voltage, Real Part L1-N (200 ms) | V | Read | |||
| Voltage, Real Part L2-N (200 ms) | V | Read | |||
| Voltage, Real Part L3-N (200 ms) | V | Read | |||
| Voltage, Real Part L4-N (200 ms) | V | Read | |||
| Voltage, Imaginary Part L1-N (200 ms) | V | Read | |||
| Voltage, Imaginary Part L2-N (200 ms) | V | Read | |||
| Voltage, Imaginary Part L3-N (200 ms) | V | Read | |||
| Voltage, Imaginary Part L4-N (200 ms) | V | Read | |||
| Current, Real Part L1 (200 ms) | A | Read | |||
| Current, Real Part L2 (200 ms) | A | Read | |||
| Current, Real Part L3 (200 ms) | A | Read | |||
| Current, Real Part L4 (200 ms) | A | Read | |||
| Current, Imaginary Part L1 (200 ms) | A | Read | |||
| Current, Imaginary Part L2 (200 ms) | A | Read | |||
| Current, Imaginary Part L3 (200 ms) | A | Read | |||
| Current, Imaginary Part L4 (200 ms) | A | Read | |||
| Phase, UL1 IL1 (200 ms) | ° | Read | |||
| Phase, UL2 IL2 (200 ms) | ° | Read | |||
| Phase, UL3 IL3 (200 ms) | ° | Read | |||
| Phase, UL4 IL4 (200 ms) | ° | Read | |||
| Fund.power Factor, CosPhi; UL1 IL1 (200 ms) | Read | ||||
| Fund.power Factor, CosPhi; UL2 IL2 (200 ms) | Read | ||||
| Fund.power Factor, CosPhi; UL3 IL3 (200 ms) | Read | ||||
| Fund.power Factor, CosPhi; UL4 IL4 (200 ms) | Read | ||||
| Sign; QL1, +1=ind., -1=cap. (200 ms) | Read | ||||
| Sign; QL2, +1=ind., -1=cap. (200 ms) | Read | ||||
| Sign; QL3, +1=ind., -1=cap. (200 ms) | Read | ||||
| Sign; QL4, +1=ind., -1=cap. (200 ms) | Read | ||||
| Measured Frequency (200 ms) | Hz | Read | |||
| Voltage, Zero Sequence (200 ms) | V | Read | |||
| Voltage, Positive Sequence (200 ms) | V | Read | |||
| Voltage, Negative Sequence (200 ms) | V | Read | |||
| Voltage, Unsymmetrical (200 ms) | % | Read | |||
| Rotation Field; 1=right, 0=none, -1=left (200 ms) | Read | ||||
| Current, Zero Sequence (200 ms) | A | Read | |||
| Current, Positive Sequence (200 ms) | A | Read | |||
| Current, Negative Sequence (200 ms) | A | Read | |||
| Internal Temperature (200 ms) | °C | Read | |||
| Sign; Q1+Q2+Q3 (200 ms) | Read | ||||
| Sign; Q1+Q2+Q3+Q4 (200 ms) | Read | ||||
| PF Total, PF_Total=P_Sum3/S_Sum3 (200 ms) | Read and write | ||||
| IN Total Demand Distortion (200 ms) | % | Read and write | |||
| IN Total Demand Distortion L2 (200 ms) | % | Read and write | |||
| IN Total Demand Distortion L3 (200 ms) | % | Read and write | |||
| IN Total Demand Distortion L4 (200 ms) | % | Read and write | |||
| Current Unsymmetrical (200 ms) | % | Read and write | |||
| ULN Crest Factor (200 ms) | Read and write | ||||
| ULN Crest Factor L2 (200 ms) | Read and write | ||||
| ULN Crest Factor L3 (200 ms) | Read and write | ||||
| ULL Crest Factor (200 ms) | Read and write | ||||
| ULL Crest Factor L2 (200 ms) | Read and write | ||||
| ULL Crest Factor L3 (200 ms) | Read and write | ||||
| IN Crest Factor (200 ms) | Read and write | ||||
| IN Crest Factor L2 (200 ms) | Read and write | ||||
| IN Crest Factor L3 (200 ms) | Read and write | ||||
| IN Crest Factor L4 (200 ms) | Read and write | ||||
| Maximum Demand Load Current, L1 (200 ms) | A | Read and write | |||
| Maximum Demand Load Current, L2 (200 ms) | A | Read and write | |||
| Maximum Demand Load Current, L3 (200 ms) | A | Read and write | |||
| Maximum Demand Load Current, L4 (200 ms) | A | Read and write | |||
| Current Rate, Real/apparent Energy | Read | ||||
| Current Rate, Reactive Energy | Read | ||||
| Apparent Energy L1 (Energy List) | VAh | Read | |||
| Apparent Energy L2 (Energy List) | VAh | Read | |||
| Apparent Energy L3 (Energy List) | VAh | Read | |||
| Apparent Energy L4 | VAh | Read | |||
| Apparent Energy L1..L3 (Energy List) | VAh | Read | |||
| Apparent Energy L1..L4 | VAh | Read | |||
| Real Energy L1 (Energy List) | Wh | Read | |||
| Real Energy L2 (Energy List) | Wh | Read | |||
| Real Energy L3 (Energy List) | Wh | Read | |||
| Real Energy L4 | Wh | Read | |||
| Real Energy L1..L3 (Energy List) | Wh | Read | |||
| Real Energy L1..L4 | Wh | Read | |||
| Reactive Energy L1 (Energy List) | varh | Read | |||
| Reactive Energy L2 (Energy List) | varh | Read | |||
| Reactive Energy L3 (Energy List) | varh | Read | |||
| Reactive Energy L4 | varh | Read | |||
| Reactive Energy L1..L3 (Energy List) | varh | Read | |||
| Reactive Energy L1..L4 | varh | Read | |||
| Real Energy L1, Consumed (Energy List) | Wh | Read | |||
| Real Energy L2, Consumed (Energy List) | Wh | Read | |||
| Real Energy L3, Consumed (Energy List) | Wh | Read | |||
| Real Energy L4, Consumed | Wh | Read | |||
| Real Energy L1..L3, Consumed | Wh | Read | |||
| Real Energy L1..L4, Consumed | Wh | Read | |||
| Real Energy L1, Delivered (Energy List) | Wh | Read | |||
| Real Energy L2, Delivered (Energy List) | Wh | Read | |||
| Real Energy L3, Delivered (Energy List) | Wh | Read | |||
| Real Energy L4, Delivered | Wh | Read | |||
| Real Energy L1..L3, Delivered (Energy List) | Wh | Read | |||
| Real Energy L1..L4, Delivered | Wh | Read | |||
| Real Energy L1, Consumed, Rate 1 | Wh | Read | |||
| Real Energy L2, Consumed, Rate 1 | Wh | Read | |||
| Real Energy L3, Consumed, Rate 1 | Wh | Read | |||
| Real Energy L4, Consumed, Rate 1 | Wh | Read | |||
| Real Energy L1..L3, Consumed, Rate 1 (Energy List) | Wh | Read | |||
| Real Energy L1..L4, Consumed, Rate 1 | Wh | Read | |||
| Real Energy L1, Consumed, Rate 2 | Wh | Read | |||
| Real Energy L2, Consumed, Rate 2 | Wh | Read | |||
| Real Energy L3, Consumed, Rate 2 | Wh | Read | |||
| Real Energy L4, Consumed, Rate 2 | Wh | Read | |||
| Real Energy L1..L3, Consumed, Rate 2 | Wh | Read | |||
| Real Energy L1..L4, Consumed, Rate 2 | Wh | Read | |||
| Real Energy L1, Delivered, Rate 1 | Wh | Read | |||
| Real Energy L2, Delivered, Rate 1 | Wh | Read | |||
| Real Energy L3, Delivered, Rate 1 | Wh | Read | |||
| Real Energy L4, Delivered, Rate 1 | Wh | Read | |||
| Real Energy L1..L3, Delivered, Rate 1 | Wh | Read | |||
| Real Energy L1..L4, Delivered, Rate 1 | Wh | Read | |||
| Real Energy L1, Delivered, Rate 2 | Wh | Read | |||
| Real Energy L2, Delivered, Rate 2 | Wh | Read | |||
| Real Energy L3, Delivered, Rate 2 | Wh | Read | |||
| Real Energy L4, Delivered, Rate 2 | Wh | Read | |||
| Real Energy L1..L3, Delivered, Rate 2 | Wh | Read | |||
| Real Energy L1..L4, Delivered, Rate 2 | Wh | Read | |||
| Reactive Energy L1, Inductive (Energy List) | varh | Read | |||
| Reactive Energy L2, Inductive (Energy List) | varh | Read | |||
| Reactive Energy L3, Inductive (Energy List) | varh | Read | |||
| Reactive Energy L4, Inductive | varh | Read | |||
| Reactive Energy L1..L3, Inductive | varh | Read | |||
| Reactive Energy L1..L4, Inductive | varh | Read | |||
| Reactive Energy L1, Capacitive (Energy List) | varh | Read | |||
| Reactive Energy L2, Capacitive (Energy List) | varh | Read | |||
| Reactive Energy L3, Capacitive (Energy List) | varh | Read | |||
| Reactive Energy L4, Capacitive | varh | Read | |||
| Reactive Energy L1..L3, Capacitive | varh | Read | |||
| Reactive Energy L1..L4, Capacitive | varh | Read | |||
| Reactive Energy L1, Inductive, Rate 1 | varh | Read | |||
| Reactive Energy L2, Inductive, Rate 1 | varh | Read | |||
| Reactive Energy L3, Inductive, Rate 1 | varh | Read | |||
| Reactive Energy L4, Inductive, Rate 1 | varh | Read | |||
| Reactive Energy L1..L3, Inductive, Rate 1 | varh | Read | |||
| Reactive Energy L1..L4, Inductive, Rate 1 | varh | Read | |||
| Reactive Energy L1, Inductive, Rate 2 | varh | Read | |||
| Reactive Energy L2, Inductive, Rate 2 | varh | Read | |||
| Reactive Energy L3, Inductive, Rate 2 | varh | Read | |||
| Reactive Energy L4, Inductive, Rate 2 | varh | Read | |||
| Reactive Energy L1..L3, Inductive, Rate 2 | varh | Read | |||
| Reactive Energy L1..L4, Inductive, Rate 2 | varh | Read | |||
| Energy Meter, Impulse Output 1 | Read | ||||
| Energy Meter, Impulse Output 2 | Read | ||||
| Runtime of Real and Apparent Energy Meas. | s | Read | |||
| Runtime of Real and Reactive Energy Meas. | s | Read | |||
| 1=delete All Real Energy Counters | Read | ||||
| 1=delete All Reactive Energy Counters | Read | ||||
| Real Energy L1, Consumed, Rate 3 | Wh | Read | |||
| Real Energy L2, Consumed, Rate 3 | Wh | Read | |||
| Real Energy L3, Consumed, Rate 3 | Wh | Read | |||
| Real Energy L4, Consumed, Rate 3 | Wh | Read | |||
| Real Energy L1..L3, Consumed, Rate 3 | Wh | Read | |||
| Real Energy L1..L4, Consumed, Rate 3 | Wh | Read | |||
| Real Energy L1, Consumed, Rate 4 | Wh | Read | |||
| Real Energy L2, Consumed, Rate 4 | Wh | Read | |||
| Real Energy L3, Consumed, Rate 4 | Wh | Read | |||
| Real Energy L4, Consumed, Rate 4 | Wh | Read | |||
| Real Energy L1..L3, Consumed, Rate 4 | Wh | Read | |||
| Real Energy L1..L4, Consumed, Rate 4 | Wh | Read | |||
| Real Energy L1, Delivered, Rate 3 | Wh | Read | |||
| Real Energy L2, Delivered, Rate 3 | Wh | Read | |||
| Real Energy L3, Delivered, Rate 3 | Wh | Read | |||
| Real Energy L4, Delivered, Rate 3 | Wh | Read | |||
| Real Energy L1..L3, Delivered, Rate 3 | Wh | Read | |||
| Real Energy L1..L4, Delivered, Rate 3 | Wh | Read | |||
| Real Energy L1, Delivered, Rate 4 | Wh | Read | |||
| Real Energy L2, Delivered, Rate 4 | Wh | Read | |||
| Real Energy L3, Delivered, Rate 4 | Wh | Read | |||
| Real Energy L4, Delivered, Rate 4 | Wh | Read | |||
| Real Energy L1..L3, Delivered, Rate 4 | Wh | Read | |||
| Real Energy L1..L4, Delivered, Rate 4 | Wh | Read | |||
| Reactive Energy L1, Inductive, Rate 3 | varh | Read | |||
| Reactive Energy L2, Inductive, Rate 3 | varh | Read | |||
| Reactive Energy L3, Inductive, Rate 3 | varh | Read | |||
| Reactive Energy L4, Inductive, Rate 3 | varh | Read | |||
| Reactive Energy L1..L3, Inductive, Rate 3 | varh | Read | |||
| Reactive Energy L1..L4, Inductive, Rate 3 | varh | Read | |||
| Reactive Energy L1, Inductive, Rate 4 | varh | Read | |||
| Reactive Energy L2, Inductive, Rate 4 | varh | Read | |||
| Reactive Energy L3, Inductive, Rate 4 | varh | Read | |||
| Reactive Energy L4, Inductive, Rate 4 | varh | Read | |||
| Reactive Energy L1..L3, Inductive, Rate 4 | varh | Read | |||
| Reactive Energy L1..L4, Inductive, Rate 4 | varh | Read | |||
| Real Energy, Month High, January, Even Year | Wh | Read | |||
| Real Energy, Month High, February, Even Year | Wh | Read | |||
| Real Energy, Month High, March, Even Year | Wh | Read | |||
| Real Energy, Month High, April, Even Year | Wh | Read | |||
| Real Energy, Month High, May, Even Year | Wh | Read | |||
| Real Energy, Month High, June, Even Year | Wh | Read | |||
| Real Energy, Month High, July, Even Year | Wh | Read | |||
| Real Energy, Month High, August, Even Year | Wh | Read | |||
| Real Energy, Month High, September, Even Year | Wh | Read | |||
| Real Energy, Month High, October, Even Year | Wh | Read | |||
| Real Energy, Month High, November, Even Year | Wh | Read | |||
| Real Energy, Month High, December, Even Year | Wh | Read | |||
| Real Energy, Month High, January, Uneven Year | Wh | Read | |||
| Real Energy, Month High, February, Uneven Year | Wh | Read | |||
| Real Energy, Month High, March, Uneven Year | Wh | Read | |||
| Real Energy, Month High, April, Uneven Year | Wh | Read | |||
| Real Energy, Month High, May, Uneven Year | Wh | Read | |||
| Real Energy, Month High, June, Uneven Year | Wh | Read | |||
| Real Energy, Month High, July, Uneven Year | Wh | Read | |||
| Real Energy, Month High, August, Uneven Year | Wh | Read | |||
| Real Energy, Month High, Sep., Uneven Year | Wh | Read | |||
| Real Energy, Month High, Oct. Uneven Year | Wh | Read | |||
| Real Energy, Month High, Nov., Uneven Year | Wh | Read | |||
| Real Energy, Month High, Dec., Uneven Year | Wh | Read | |||
| Apparent Energy, Month High, Jan. Even Year | VAh | Read | |||
| Apparent Energy, Month High, Feb., Even Year | VAh | Read | |||
| Apparent Energy, Month High, March, Even Year | VAh | Read | |||
| Apparent Energy, Month High, April, Even Year | VAh | Read | |||
| Apparent Energy, Month High, May, Even Year | VAh | Read | |||
| Apparent Energy, Month High, June, Even Year | VAh | Read | |||
| Apparent Energy, Month High, July, Even Year | VAh | Read | |||
| Apparent Energy, Month High, Aug., Even Year | VAh | Read | |||
| Apparent Energy, Month High, Sep., Even Year | VAh | Read | |||
| Apparent Energy, Month High, Oct., Even Year | VAh | Read | |||
| Apparent Energy, Month High, Nov., Even Year | VAh | Read | |||
| Apparent Energy, Month High, Dec., Even Year | VAh | Read | |||
| Apparent Energy, Month High, Jan., Uneven Year | VAh | Read | |||
| Apparent Energy, Month High, Feb., Uneven Year | VAh | Read | |||
| Apparent Energy, Month High, March, Uneven Year | VAh | Read | |||
| Apparent Energy, Month High, April, Uneven Year | VAh | Read | |||
| Apparent Energy, Month High, May, Uneven Year | VAh | Read | |||
| Apparent Energy, Month High, June, Uneven Year | VAh | Read | |||
| Apparent Energy, Month High, July, Uneven Year | VAh | Read | |||
| Apparent Energy, Month High, Aug., Uneven Year | VAh | Read | |||
| Apparent Energy, Month High, Sep., Uneven Year | VAh | Read | |||
| Apparent Energy, Month High, Oct., Uneven Year | VAh | Read | |||
| Apparent Energy, Month High, Nov., Uneven Year | VAh | Read | |||
| Apparent Energy, Month High, Dec., Uneven Year | VAh | Read | |||
| Reactive Energy, Month High, Jan., Even Year | varh | Read | |||
| Reactive Energy, Month High, Feb., Even Year | varh | Read | |||
| Reactive Energy, Month High, March, Even Year | varh | Read | |||
| Reactive Energy, Month High, April, Even Year | varh | Read | |||
| Reactive Energy, Month High, May, Even Year | varh | Read | |||
| Reactive Energy, Month High, June, Even Year | varh | Read | |||
| Reactive Energy, Month High, July, Even Year | varh | Read | |||
| Reactive Energy, Month High, Aug., Even Year | varh | Read | |||
| Reactive Energy, Month High, Sep., Even Year | varh | Read | |||
| Reactive Energy, Month High, Oct., Even Year | varh | Read | |||
| Reactive Energy, Month High, Nov., Even Year | varh | Read | |||
| Reactive Energy, Month High, Dec., Even Year | varh | Read | |||
| Reactive Energy, Month High, Jan., Uneven Year | varh | Read | |||
| Reactive Energy, Month High, Feb., Uneven Year | varh | Read | |||
| Reactive Energy, Month High, March, Uneven Year | varh | Read | |||
| Reactive Energy, Month High, April, Uneven Year | varh | Read | |||
| Reactive Energy, Month High, May, Uneven Year | varh | Read | |||
| Reactive Energy, Month High, June, Uneven Year | varh | Read | |||
| Reactive Energy, Month High, July, Uneven Year | varh | Read | |||
| Reactive Energy, Month High, Aug., Uneven Year | varh | Read | |||
| Reactive Energy, Month High, Sep, Uneven Year | varh | Read | |||
| Reactive Energy, Month High, Oct., Uneven Year | varh | Read | |||
| Reactive Energy, Month High, Nov, Uneven Year | varh | Read | |||
| Reactive Energy, Month High, Dec., Uneven Year | varh | Read | |||
| Average, Harmonics, THD; U L1-N | % | Read | |||
| Average, Harmonics, THD; U L2-N | % | Read | |||
| Average, Harmonics, THD; U L3-N | % | Read | |||
| Average, Harmonics, THD; U L4-N | % | Read | |||
| Average, Harmonics, THD; I L1 | % | Read | |||
| Average, Harmonics, THD; I L2 | % | Read | |||
| Average, Harmonics, THD; I L3 | % | Read | |||
| Average, Harmonics, THD; I L4 | % | Read | |||
| Average, K-Factor, L1 | Read | ||||
| Average, K-Factor, L2 | Read | ||||
| Average, K-Factor, L3 | Read | ||||
| Average, K-Factor, L4 | Read | ||||
| Average, U L1-N | V | Read | |||
| Average, U L2-N | V | Read | |||
| Average, U L3-N | V | Read | |||
| Average, U L4-N | V | Read | |||
| Average, I L | A | Read | |||
| Average, I L L2 | A | Read | |||
| Average, I L L3 | A | Read | |||
| Average, I L L4 | A | Read | |||
| Average, P L1 | W | Read | |||
| Average, P L2 | W | Read | |||
| Average, P L3 | W | Read | |||
| Average, P L4 | W | Read | |||
| Average, Q L1 | var | Read | |||
| Average, Q L2 | var | Read | |||
| Average, Q L3 | var | Read | |||
| Average, Q L4 | var | Read | |||
| Average, S L1 | VA | Read | |||
| Average, S L2 | VA | Read | |||
| Average, S L3 | VA | Read | |||
| Average, S L4 | VA | Read | |||
| Average, U L1-L2 | V | Read | |||
| Average, U L2-L3 | V | Read | |||
| Average, U L3-L1 | V | Read | |||
| Average, IN=I1+I2+I3 | A | Read | |||
| Average, Isum=I1+I2+I3+I4 | A | Read | |||
| Average, Ssum3=S1+S2+S3 | VA | Read | |||
| Average, Psum3=P1+P2+P3 | W | Read | |||
| Average, Qsum3=Q1+Q2+Q3 | var | Read | |||
| Average, Ssum=S1+S2+S3+S4 | VA | Read | |||
| Average, Psum=P1+P2+P3+P4 | W | Read | |||
| Average, Qsum=Q1+Q2+Q3+Q4 | var | Read | |||
| Average Frequency | Hz | Read | |||
| Average, Voltage, Zero Sequence | V | Read | |||
| Average, Voltage, Positive Sequence | V | Read | |||
| Average, Voltage, Negative Sequence | V | Read | |||
| Average, Unsymmetrical Voltage | % | Read | |||
| Average, Current, Zero Sequence | A | Read | |||
| Average, Current, Positive Sequence | A | Read | |||
| Average, Current, Negative Sequence | A | Read | |||
| Average, Input, Measured Value | W | Read | |||
| Average, Input, Measured Value L2 | W | Read | |||
| Average, Internal Temperature | °C | Read | |||
| Mean Value, ULN=(UL1+UL2+UL3)/3 | V | Read and write | |||
| Mean Value, ULL=(ULL1+ULL2+ULL3)/3 | V | Read and write | |||
| Mean Value, IN=(I1+I2+I3)/3 | V | Read and write | |||
| Mean Value, Total Demand Distortion | % | Read and write | |||
| Minimum, Harmonics, THD; U L1-N | % | Read | |||
| Minimum, Harmonics, THD; U L2-N | % | Read | |||
| Minimum, Harmonics, THD; U L3-N | % | Read | |||
| Minimum, Harmonics, THD; U L4-N | % | Read | |||
| Minimum, U L1-N | V | Read | |||
| Minimum, U L2-N | V | Read | |||
| Minimum, U L3-N | V | Read | |||
| Minimum, U L4-N | V | Read | |||
| Minimum, U L1-L2 | V | Read | |||
| Minimum, U L2-L3 | V | Read | |||
| Minimum, U L3-L1 | V | Read | |||
| Minimum, Frequency | Hz | Read | |||
| Minimum, Zero Sequence Voltage | V | Read | |||
| Minimum, Positive Sequence Voltage | V | Read | |||
| Minimum, Negative Sequence Voltage | V | Read | |||
| Minimum, Unsymmetrical Voltage | % | Read | |||
| Minimum, Internal Temperature | °C | Read | |||
| Maximum, Harmonics, THD; U L1-N | % | Read | |||
| Maximum, Harmonics, THD; U L2-N | % | Read | |||
| Maximum, Harmonics, THD; U L3-N | % | Read | |||
| Maximum, Harmonics, THD; U L4-N | % | Read | |||
| Maximum, Harmonics, THD; I L1-N | % | Read | |||
| Maximum, Harmonics, THD; I L2-N | % | Read | |||
| Maximum, Harmonics, THD; I L3-N | % | Read | |||
| Maximum, Harmonics, THD; I L4-N | % | Read | |||
| Maximum, K-Factor | Read | ||||
| Maximum, K-Factor L2 | Read | ||||
| Maximum, K-Factor L3 | Read | ||||
| Maximum, K-Factor L4 | Read | ||||
| Maximum, U L1-N | V | Read | |||
| Maximum, U L2-N | V | Read | |||
| Maximum, U L3-N | V | Read | |||
| Maximum, U L4-N | V | Read | |||
| Maximum, I L1 | A | Read | |||
| Maximum, I L2 | A | Read | |||
| Maximum, I L3 | A | Read | |||
| Maximum, I L4 | A | Read | |||
| Maximum, P L1 | W | Read | |||
| Maximum, P L2 | W | Read | |||
| Maximum, P L3 | W | Read | |||
| Maximum, P L4 | W | Read | |||
| Maximum, Q L1 | var | Read | |||
| Maximum, Q L2 | var | Read | |||
| Maximum, Q L3 | var | Read | |||
| Maximum, Q L4 | var | Read | |||
| Maximum, S L1 | VA | Read | |||
| Maximum, S L2 | VA | Read | |||
| Maximum, S L3 | VA | Read | |||
| Maximum, S L4 | VA | Read | |||
| Maximum, U L1-L2 | V | Read | |||
| Maximum, U L2-L3 | V | Read | |||
| Maximum, U L3-L1 | V | Read | |||
| Maximum, IN = I1 + I2 + I3 | A | Read | |||
| Maximum, I1 + I2 + I3 + I4 | A | Read | |||
| Maximum, Ssum3 = S1 + S2 + S3 | VA | Read | |||
| Maximum, Psum3 = P1 + P2 + P3 | W | Read | |||
| Maximum, Qsum3 = Q1 + Q2 + Q3 | var | Read | |||
| Maximum, Ssum = S1 + S2 + S3 + S4 | VA | Read | |||
| Maximum, Psum = P1 + P2 + P3 + P4 | W | Read | |||
| Maximum, Qsum = Q1 + Q2 + Q3 + Q4 | var | Read | |||
| Maximum, Frequency | Hz | Read | |||
| Maximum, Zero Sequence Voltage | V | Read | |||
| Maximum, Positive Sequence Voltage | V | Read | |||
| Maximum, Negative Sequence Voltage | V | Read | |||
| Maximum, Unsymmetrical Voltage | % | Read | |||
| Maximum, Zero Sequence Current | A | Read | |||
| Maximum, Positive Sequence Current | A | Read | |||
| Maximum, Negative Sequence Current | A | Read | |||
| Maximum, Input, Measured Value | W | Read | |||
| Maximum, Input, Measured Value L2 | W | Read | |||
| Maximum, Internal Temperature | °C | Read | |||
| Max. Values of Average Val., THD U L1-N | % | Read | |||
| Max. Values of Average Val., THD U L2-N | % | Read | |||
| Max. Values of Average Val., THD U L3-N | % | Read | |||
| Max. Values of Average Val., THD U L4-N | % | Read | |||
| Max. Values of Average Val., THD I L1 | % | Read | |||
| Max. Values of Average Val., THD I L2 | % | Read | |||
| Max. Values of Average Val., THD I L3 | % | Read | |||
| Max. Values of Average Val., THD I L4 | % | Read | |||
| Max. Values of Average Val., K-Factor L1 | Read | ||||
| Max. Values of Average Val., K-Factor L2 | Read | ||||
| Max. Values of Average Val., K-Factor L3 | Read | ||||
| Max. Values of Average Val., K-Factor L4 | Read | ||||
| Max. Values of Average Val., U L1-N | V | Read | |||
| Max. Values of Average Val., U L2-N | V | Read | |||
| Max. Values of Average Val., U L3-N | V | Read | |||
| Max. Values of Average Val., U L4-N | V | Read | |||
| Max. Values of Average Val., I L1 | A | Read | |||
| Max. Values of Average Val., I L2 | A | Read | |||
| Max. Values of Average Val., I L2 ILN_AVG_MAX[2] | A | Read | |||
| Max. Values of Average Val., I L3 | A | Read | |||
| Max. Values of Average Val., P L1 | W | Read | |||
| Max. Values of Average Val., P L2 | W | Read | |||
| Max. Values of Average Val., P L3 | W | Read | |||
| Max. Values of Average Val., P L4 | W | Read | |||
| Max. Values of Average Val., Q L1 | var | Read | |||
| Max. Values of Average Val., Q L2 | var | Read | |||
| Max. Values of Average Val., Q L3 | var | Read | |||
| Max. Values of Average Val., Q L4 | var | Read | |||
| Max. Values of Average Val., S L1 | VA | Read | |||
| Max. Values of Average Val., S L2 | VA | Read | |||
| Max. Values of Average Val., S L3 | VA | Read | |||
| Max. Values of Average Val., S L4 | VA | Read | |||
| Max. Values of Average Val., U L1-L2 | V | Read | |||
| Max. Values of Average Val., U L2-L3 | V | Read | |||
| Max. Values of Average Val., U L3-L1 | V | Read | |||
| Max. Values of Average Val., IN = I1 + I2 + I3 | A | Read | |||
| Max. Values of Average Val., I1 + I2 + I3 + I4 | A | Read | |||
| Max. Values of Average Val., S = S1 + S2 + S3 | VA | Read | |||
| Max. Values of Average Val., P = P1 + P2 + P3 | W | Read | |||
| Max. Values of Average Val., Q = Q1 + Q2 + Q3 | var | Read | |||
| Max. Values of Average Val., S = S1 + S2 + S3 S_SUM_AVG_MAX | VA | Read | |||
| Max. Values of Average Val., P = P1 + P2 + P3 P_SUM_AVG_MAX | W | Read | |||
| Max. Values of Average Val., Q = Q1 + Q2 + Q3 Q_SUM_AVG_MAX | var | Read | |||
| Max. Values of Average Val., Frequency | Hz | Read | |||
| Max. Values of Average Val., Zero Sequence Voltage | V | Read | |||
| Max. Values of Average Val., Zero Positive Voltage | V | Read | |||
| Max. Values of Average Val., Zero Negative Voltage | V | Read | |||
| Max. Values of Average Val., Unsymmetrical Voltage | % | Read | |||
| Max. Values of Average Val., Zero Sequence Current | A | Read | |||
| Max. Values of Average Val., Zero Positive Current | A | Read | |||
| Max. Values of Average Val., Zero Negative Current | A | Read | |||
| Max. Val. of Average Val., Input, Measured Value | W | Read | |||
| Max. Val. of Average Val., Input, Measured Value L2 | W | Read | |||
| Max. Val. of Average Val., Internal Temperature | Read | ||||
| Time of Min. Val. (UTC), Harmonics, THD U L1-N | s | Read | |||
| Time of Min. Val. (UTC), Harmonics, THD U L2-N | s | Read | |||
| Time of Min. Val. (UTC), Harmonics, THD U L3-N | s | Read | |||
| Time of Min. Val. (UTC), Harmonics, THD U L4-N | s | Read | |||
| Time of Min. Val. (UTC), U L1-N | s | Read | |||
| Time of Min. Val. (UTC), U L2-N | s | Read | |||
| Time of Min. Val. (UTC), U L3-N | s | Read | |||
| Time of Min. Val. (UTC), U L4-N | s | Read | |||
| Time of Min. Val. (UTC), U L1-L2 | s | Read | |||
| Time of Min. Val. (UTC), U L2-L3 | s | Read | |||
| Time of Min. Val. (UTC), U L3-L1 | s | Read | |||
| Time of Min. Val. (UTC), Frequency | s | Read | |||
| Time of Min. Val. (UTC), Zero Sequence Voltage | s | Read | |||
| Time of Min. Val. (UTC), Zero Positive Voltage | s | Read | |||
| Time of Min. Val. (UTC), Zero Negative Voltage | s | Read | |||
| Time of Min. Val. (UTC), Input, Measured Value | s | Read | |||
| Time of Min. Val. (UTC), Internal Temperature | s | Read | |||
| Time of Max. Value (UTC), Harmonics, THD U L1-N | s | Read | |||
| Time of Max. Value (UTC), Harmonics, THD U L2-N | s | Read | |||
| Time of Max. Value (UTC), Harmonics, THD U L3-N | s | Read | |||
| Time of Max. Value (UTC), Harmonics, THD U L4-N | s | Read | |||
| Time of Max. Value (UTC), Harmonics, THD I L1 | s | Read | |||
| Time of Max. Value (UTC), Harmonics, THD I L2 | s | Read | |||
| Time of Max. Value (UTC), Harmonics, THD I L3 | s | Read | |||
| Time of Max. Value (UTC), Harmonics, THD I L4 | s | Read | |||
| Time of Max. Value (UTC), K-Factor L1 | s | Read | |||
| Time of Max. Value (UTC), K-Factor L2 | s | Read | |||
| Time of Max. Value (UTC), K-Factor L3 | s | Read | |||
| Time of Max. Value (UTC), K-Factor L4 | s | Read | |||
| Time of Max. Value (UTC), U L1-N | s | Read | |||
| Time of Max. Value (UTC), U L2-N | s | Read | |||
| Time of Max. Value (UTC), U L3-N | s | Read | |||
| Time of Max. Value (UTC), U L4-N | s | Read | |||
| Time of Max. Value (UTC), I L1 | s | Read | |||
| Time of Max. Value (UTC), I L2 | s | Read | |||
| Time of Max. Value (UTC), I L3 | s | Read | |||
| Time of Max. Value (UTC), I L4 | s | Read | |||
| Time of Max. Value (UTC), P L1 | s | Read | |||
| Time of Max. Value (UTC), P L2 | s | Read | |||
| Time of Max. Value (UTC), P L3 | s | Read | |||
| Time of Max. Value (UTC), P L4 | s | Read | |||
| Time of Max. Value (UTC), Q L1 | s | Read | |||
| Time of Max. Value (UTC), Q L2 | s | Read | |||
| Time of Max. Value (UTC), Q L3 | s | Read | |||
| Time of Max. Value (UTC), Q L4 | s | Read | |||
| Time of Max. Value (UTC), S L1 | s | Read | |||
| Time of Max. Value (UTC), S L2 | s | Read | |||
| Time of Max. Value (UTC), S L3 | s | Read | |||
| Time of Max. Value (UTC), S L4 | s | Read | |||
| Time of Max. Value (UTC), U L1-L2 | s | Read | |||
| Time of Max. Value (UTC), U L2-L3 | s | Read | |||
| Time of Max. Value (UTC), U L3-L1 | s | Read | |||
| Time of Max. Value (UTC), IN = I1 + I2 + I3 | s | Read | |||
| Time of Max. Value (UTC), I1 + I2 + I3 + I4 | s | Read | |||
| Time of Max. Value (UTC), S1 + S2 + S3 | s | Read | |||
| Time of Max. Value (UTC), P1 + P2 + P3 | s | Read | |||
| Time of Max. Value (UTC), Q1 + Q2 + Q3 | s | Read | |||
| Time of Max. Value (UTC), S1 + S2 + S3 + S4 | s | Read | |||
| Time of Max. Value (UTC), P1 + P2 + P3 + P4 | s | Read | |||
| Time of Max. Value (UTC), Q1 + Q2 + Q3 + Q4 | s | Read | |||
| Time of Max. Value (UTC), Frequency | s | Read | |||
| Time of Max. Val. (UTC), Zero Sequence Voltage | s | Read | |||
| Time of Max. Val. (UTC), Zero Positive Voltage | s | Read | |||
| Time of Max. Val. (UTC), Zero Negative Voltage | s | Read | |||
| Time of Max. Val. (UTC), Unsymmetrical Voltage | s | Read | |||
| Time of Max. Val. (UTC), Zero Sequence Current | s | Read | |||
| Time of Max. Val. (UTC), Zero Positive Current | s | Read | |||
| Time of Max. Val. (UTC), Zero Negative Current | s | Read | |||
| Time of Max. Val. (UTC), Input, Measured Value | s | Read | |||
| Time of Max. Val. (UTC), Input, Measured Value L2 | s | Read | |||
| Time of Max. Val.(UTC), Internal Temperature | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), THD U L1 | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), THD U L2 | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), THD U L3 | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), THD U L4 | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), THD I L1 | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), THD I L2 | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), THD I L3 | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), THD I L4 | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), K-Factor L1 | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), K-Factor L2 | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), K-Factor L3 | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), K-Factor L4 | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), U L1-N | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), U L2-N | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), U L3-N | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), U L4-N | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), I L1 | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), I L2 | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), I L3 | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), I L4 | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), P L1 | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), P L2 | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), P L3 | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), P L4 | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), Q L1 | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), Q L2 | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), Q L3 | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), Q L4 | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), S L1 | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), S L2 | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), S L3 | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), S L4 | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), U L1-L2 | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), U L2-L3 | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), U L3-L1 | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), IN = I1 + I2 + I3 | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), I1 + I2 + I3 + I4 | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC),S1 + S2 + S3 | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC) P SUM3 AVG MAX T | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC) Q SUM3 AVG MAX T | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC) S SUM AVG MAX T | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC) P SUM AVG MAX T | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC) Q SUM AVG MAX T | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), Frequency | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC), I1 + I2 + I3 + I4 N_AVG_MA | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC) M AVG MAX T | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC) G AVG MAX T | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC) SYM AVG MAX T | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC) IN AVG MAX T | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC) IM AVG MAX T | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC) IG AVG MAX T | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC) S0 POWER AVG MAX T | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC) S0 POWER AVG MAX T L2 | s | Read | |||
| Time of Max. Val. of Aver. Val.(UTC) EXT TEMPERATUR AVG MAX T S | Read | ||||
| Averaging Time, Harmonics, THD, U L1-N | Read | ||||
| Averaging Time, Harmonics, THD, U L2-N | Read | ||||
| Averaging Time, Harmonics, THD, U L3-N | Read | ||||
| Averaging Time, Harmonics, THD, U L4-N | Read | ||||
| Averaging Time, Harmonics, THD, I L1 | Read | ||||
| Averaging Time, Harmonics, THD, I L2 | Read | ||||
| Averaging Time, Harmonics, THD, I L3 | Read | ||||
| Averaging Time, Harmonics, THD, I L4 | Read | ||||
| Averaging Time, K-Factor L1 | Read | ||||
| Averaging Time, K-Factor L2 | Read | ||||
| Averaging Time, K-Factor L3 | Read | ||||
| Averaging Time, K-Factor L4 | Read | ||||
| Averaging Time, U L1-N | Read | ||||
| Averaging Time, U L2-N | Read | ||||
| Averaging Time, U L3-N | Read | ||||
| Averaging Time, U L4-N | Read | ||||
| Averaging Time, I L1 | Read | ||||
| Averaging Time, I L2 | Read | ||||
| Averaging Time, I L3 | Read | ||||
| Averaging Time, I L4 | Read | ||||
| Averaging Time, P L1 | Read | ||||
| Averaging Time, P L2 | Read | ||||
| Averaging Time, P L3 | Read | ||||
| Averaging Time, P L4 | Read | ||||
| Averaging Time, Q L1 | Read | ||||
| Averaging Time, Q L2 | Read | ||||
| Averaging Time, Q L3 | Read | ||||
| Averaging Time, Q L4 | Read | ||||
| Averaging Time, S L1 | Read | ||||
| Averaging Time, S L2 | Read | ||||
| Averaging Time, S L3 | Read | ||||
| Averaging Time, S L4 | Read | ||||
| Averaging Time, U L1-L2 | Read | ||||
| Averaging Time, U L2-L3 | Read | ||||
| Averaging Time, U L3-L1 | Read | ||||
| Averaging Time, IN = I1 + I2 + I3 | Read | ||||
| Averaging Time, I1 + I2 + I3 + I4 | Read | ||||
| Averaging Time, S = S1 + S2 + S3 | Read | ||||
| Averaging Time, P = P1 + P2 + P3 | Read | ||||
| Averaging Time, Q = Q1 + Q2 + Q3 | Read | ||||
| Averaging Time, S1 + S2 + S3 + S4 | Read | ||||
| Averaging Time, P1 + P2 + P3 + P4 | Read | ||||
| Averaging Time, Q1 + Q2 + Q3 + Q4 | Read | ||||
| Averaging Time, Frequency | Read | ||||
| Averaging Time, Zero Sequence Voltage | Read | ||||
| Averaging Time, Positive Sequence Voltage | Read | ||||
| Averaging Time, Negative Sequence Voltage | Read | ||||
| Averaging Time, Unsymmetrical Voltage | Read | ||||
| Averaging Time, Zero Sequence Current | Read | ||||
| Averaging Time, Positive Sequence Current | Read | ||||
| Averaging Time, Negative Sequence Current | Read | ||||
| Averaging Time, Input, Measured Value | Read | ||||
| Averaging Time, Input, Measured Value L2 | Read | ||||
| Averaging Time, Internal Temperature | Read | ||||
| Time (UTC) REALTIME | Read | ||||
| Time (UTC) SYSTIME | s | Read and write | |||
| Day (1..31) | Read | ||||
| Month (0=Jan, .. 11=Dec) | Read | ||||
| Year | Read | ||||
| Hour (1..24) | h | Read | |||
| Minute (1..59) | min | Read | |||
| Second (1..59) | s | Read | |||
| Weekday (0=Sun, .. 6=Sat) | Read | ||||
| Ptp Version | Read | ||||
| Ptp Domain | Read and write | ||||
| Ptp Clock Class | Read | ||||
| Ptp Clock Accuracy | Read | ||||
| Ptp Time Source | Read | ||||
| Ptp Two Step | Read | ||||
| Ptp Delay Mechanism | Read | ||||
| Ptp Profile Id | Read | ||||
| Ptp Profile Id L2 | Read | ||||
| Ptp Profile Id L3 | Read | ||||
| Ptp Profile Id L4 | Read | ||||
| Ptp Profile Id L5 | Read | ||||
| Ptp Profile Id L6 | Read | ||||
| PTP ANNOUNCE RECEIPT TIMEOUT Only for Internal Use | Read and write | ||||
| Ptp State | Read | ||||
| Ptp Management Interface | Read and write | ||||
| Ptp Priority1 | Read and write | ||||
| Ptp Priority2 | Read and write | ||||
| Star Connection Voltage | V | Read | |||
| Status Digital Output, 0=not Active, 1=active | Read and write | ||||
| Status Digital Output, 0=not Active, 1=active L2 | Read and write | ||||
| Status Digital Input, 0=not Active, 1=active | Read | ||||
| Status Digital Input, 0=not Active, 1=active L2 | Read | ||||
| Event Counter | Read and write | ||||
| Flag Counter | Read and write | ||||
| Error Counter, Transients | Read and write | ||||
| Error Counter, Half-cycle Effective Val. | Read and write | ||||
| Error Counter, Receive RS232 | Read and write | ||||
| Error Counter, Send RS232 | Read and write | ||||
| Error Counter, RS232 | Read and write | ||||
| Error Counter, Receive RS485 | Read and write | ||||
| Error Counter, Send RS485 | Read and write | ||||
| Error Counter, RS485 | Read and write | ||||
| Run | Read and write | ||||
| Current Transf., Primary L1 | A | Read and write | |||
| Current Transf., Primary L2 | A | Read and write | |||
| Current Transf., Primary L3 | A | Read and write | |||
| Current Transf., Primary L4 | A | Read and write | |||
| Current Transf., Secondary L1 | A | Read and write | |||
| Current Transf., Secondary L2 | A | Read and write | |||
| Current Transf., Secondary L3 | A | Read and write | |||
| Current Transf., Secondary L4 | A | Read and write | |||
| Voltage Transf., Primary L1 | V | Read and write | |||
| Voltage Transf., Primary L2 | V | Read and write | |||
| Voltage Transf., Primary L3 | V | Read and write | |||
| Voltage Transf., Primary L4 | V | Read and write | |||
| Voltage Transf., Secondary L1 | V | Read and write | |||
| Voltage Transf., Secondary L2 | V | Read and write | |||
| Voltage Transf., Secondary L3 | V | Read and write | |||
| Voltage Transf., Secondary L4 | V | Read and write | |||
| Nominal Current Transformer L1 | A | Read and write | |||
| Nominal Current Transformer L2 | A | Read and write | |||
| Nominal Current Transformer L3 | A | Read and write | |||
| Nominal Current Transformer L4 | A | Read and write | |||
| Dev Name | Read and write | ||||
| Dev Desc | Read and write | ||||
| Language | Read and write | ||||
| Disp Language | Read and write | ||||
| Sernr | Read | ||||
| Prodnr | Read | ||||
| RS485, Modbus Address | Read and write | ||||
| RS485, Modbus Mode | Read and write | ||||
| RS485, Baudrate | Read and write | ||||
| Network Address | Read | ||||
| Network Mask | Read | ||||
| Gateway Address | Read | ||||
| 1=DHCP On, 0=DHCP Off | Read and write | ||||
| Brightness Display | Read and write | ||||
| Standby Time | Read and write | ||||
| Standby Contrast | Read and write | ||||
| Screensaver, 1=on, 0=off | Read and write | ||||
| Display Change Time | Read and write | ||||
| 0=autom. Display Change | Read and write | ||||
| Rotation Time Display | Read and write | ||||
| Status, Button 1 | Read and write | ||||
| Status, Button 2 | Read and write | ||||
| Status, Button 3 | Read and write | ||||
| Status, Button 4 | Read and write | ||||
| Status, Button 5 | Read and write | ||||
| Status, Button 6 | Read and write | ||||
| Debug Ip | Read and write | ||||
| Time Zone | s | Read and write | |||
| Stime | s | Read and write | |||
| Start Day of Summer/winter Switchover | Read and write | ||||
| Shour | h | Read and write | |||
| Smon | Read and write | ||||
| Smin | min | Read and write | |||
| Summer/winter Switchover | Read and write | ||||
| Eday | Read and write | ||||
| Ehour | h | Read and write | |||
| Emon | Read and write | ||||
| Emin | min | Read and write | |||
| Edow | Read and write | ||||
| Nominal Voltage U L1 | V | Read | |||
| Nominal Voltage U L2 | V | Read | |||
| Nominal Voltage U L3 | V | Read | |||
| Nominal Voltage U L4 | V | Read | |||
| Nominal Current I L1 | A | Read | |||
| Nominal Current I L2 | A | Read | |||
| Nominal Current I L3 | A | Read | |||
| Nominal Current I L4 | A | Read | |||
| Nominal Frequency | Hz | Read | |||
| 1=DHCP On, 0=DHCP Off (Settings) | Read and write | ||||
| Network Address (Settings) | Read and write | ||||
| Network Mask (Settings) | Read and write | ||||
| Brightness Display (Settings) | Read and write | ||||
| Standby Time (Settings) | Read and write | ||||
| Standby Contrast (Settings) | Read and write | ||||
| Screensave | Read and write | ||||
| Disp Mode | Read and write | ||||
| Rotate | Read and write | ||||
| Rotation Time, Display | Read and write | ||||
| Password, Guest | Read and write | ||||
| Password, User | Read and write | ||||
| Password, Admin | Read and write | ||||
| Pulse Value for Input 1 | Read and write | ||||
| Pulse Value for Input 2 | Read and write | ||||
| Mode Ntp | Read and write | ||||
| Temperatur Offset | °C | Read and write | |||
| Release | Read | ||||
| Download | Read and write | ||||
| Dummy | Read | ||||
| Gateway Timeout | ms | Read and write | |||
| Device Hardware Index | Read | ||||
| Puls Width | Read and write | ||||
| Metering Range Monitoring | Read and write | ||||
| Time (UTC) SET SYSTIME | s | Read and write | |||
| Transients | Read and write | ||||
| Mode Env | Read and write | ||||
| Trnsenv | Read and write | ||||
| Snmp Oid | Read | ||||
| SMTP-Port | Read and write | ||||
| Power Factor; L1 | Read | ||||
| Power Factor; L2 | Read | ||||
| Power Factor; L3 | Read | ||||
| Power Factor; L4 | Read | ||||
| Time of Record | Read and write | ||||
| Voltage Threshold Without Transformer | V | Read and write | |||
| Current Threshold Without Transformer | A | Read and write | |||
| PHASE MODE | Read and write | ||||
| Configure Bacnet Foreign Device Registration: | Read and write | ||||
| Configure Bacnet Foreign Device Registration: (Settings) | Read and write | ||||
| BACnet Network Number for Vnet | Read and write | ||||
| Disable Underscore Before Object Names (1) | Read and write | ||||
| Current Transformer I5, Primary 1 | A | Read and write | |||
| Current Transformer I6, Primary 2 | A | Read and write | |||
| Current Transformer I5, Secondary 1 | A | Read and write | |||
| Current Transformer I6, Secondary 2 | A | Read and write | |||
| Failure Monitoring, Diff 1 | A | Read and write | |||
| Failure Monitoring, Diff 2 | A | Read and write | |||
| Thermal Element | Read and write | ||||
| IDIFF | A | Read and write | |||
| IDIFF L2 | A | Read and write | |||
| External Temperatur | °C | Read | |||
| Connection to Current Transformer, Diff 1 | Read and write | ||||
| Connection to Current Transformer, Diff 2 | Read and write | ||||
| Alarm Status for Diff 1 With: | s | Read and write | |||
| Alarm Status for Diff 2 With: | s | Read and write | |||
| Overcurrent Duration Diff0 | s | Read and write | |||
| Overcurrent Duration Diff0 L2 | s | Read and write | |||
| Real Threshold Diff 0 | A | Read and write | |||
| Real Threshold Diff 0 L2 | A | Read and write | |||
| Name, Input 1 | Read and write | ||||
| Unit, Input 1 | Read and write | ||||
| Description, Input 1 | Read and write | ||||
| Name, Input 2 | Read and write | ||||
| Unit, Input 2 | Read and write | ||||
| Description, Input 2 | Read and write | ||||
| IN Distortion Reactive Power | var | Read and write | |||
| IN Distortion Reactive Power L2 | var | Read and write | |||
| IN Distortion Reactive Power L3 | var | Read and write | |||
| IN Distortion Reactive Power L4 | var | Read and write | |||
| Voltage, Real Part L-L | V | Read and write | |||
| Voltage, Real Part L-L L2 | V | Read and write | |||
| Voltage, Real Part L-L L3 | V | Read and write | |||
| Voltage, Imaginary Part L-L | V | Read and write | |||
| Voltage, Imaginary Part L-L L2 | V | Read and write | |||
| Voltage, Imaginary Part L-L L3 | V | Read and write | |||
| Counter for Started Events | Read | ||||
| Flags for Running Events | Read | ||||
| Free Input Field for Storing Numerical Information | Read and write |
Loading registers…
Send your device list
If a device is not in the library yet, we build the template for free as soon as we have the register data.
Use cases
- Show voltages, currents and total power of a main distribution on a ModbusCloud dashboard.
- Send an email alert when THD voltage or voltage unbalance exceeds the limit you set.
- Keep a year of energy per phase and tariff to allocate costs to departments or tenants.
- Compare maximum demand values with the rated transformer current to see how much capacity is left.
- Correct a current transformer ratio remotely after a change in the installation.
Installation
Connect RS485 A and B of the UMG 509-PRO to RS485 A and B of the ModbusCloud Gateway and terminate both ends of the bus.
On the meter set a unique Modbus address and the baud rate, with 8 data bits, no parity and 2 stop bits.
In ModbusCloud add a Modbus device with the same address and serial settings and import this template.
Check that the voltages L1-N to L3-N and the frequency show plausible values before you write any setting.
Things to watch for
The meter does not answer. What should I check?
Check address, baud rate, 8 data bits, no parity and 2 stop bits on both sides. Swap A and B if needed and make sure the bus is terminated at both ends and nowhere else.
Why are current and power values too low by a fixed factor?
Values in the short format do not include the transformer ratio, float values do. Use the float registers, and check that the current and voltage transformer ratios in the meter match the installed transformers.
Can I change settings over Modbus?
Yes, settings such as transformer ratios, Modbus address, baud rate and display options are writable. Read the current value first and change one setting at a time; a wrong transformer ratio changes every measured value and energy counter from that moment.
Where are the individual harmonics?
This template holds the measured values, energy, statistics and settings. The individual harmonics per order are a separate, very large block in the meter and are not included here.
Want to see how it works?
